rossignol Enduro Heretic SLX, Enduro Heretic SLX 2022
2022 Mountain
Estimate price |
4,187$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox ZEB Select+
-
Groupset SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail 160mm travel | 6061 Alloy
Suspension Fork
RockShox ZEB Select+ CHARGER 2 RC, BOOST 15X110 MXL STEALTH, DEBONAIR 160, gloss black,
Rear Shock
Rockshox Super Deluxe Select+ RT 185x55 Debonair 2 Tokens Mm Tune 320lb Threshold Trunnion Standard B 8x30mm Lower Mount
Drivetrain
Rear Derailleur
Shimano SLX M7100, SGS
Shift Levers
Shimano SLX M7100, ISPEC EV
Cassette
Shimano SLX M7100, 10-51T
Crank
Shimano SLX M7100, 32T; XS, S, M, L: 170mm / XL: 175mm
Bottom Bracket
Threaded; Shimano XT MT800;
Chain
Shimano Deore M6100
Chain Guide
e*thirteen TRS
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano SLX M7110 | J-Bend, Center Lock, 28h, TA 15x110
Rear Hub
Shimano SLX M7110 | J-Bend, Center Lock, 28h, TA 12x148, Micro Spline
Rims
e*thirteen LG1 Base Trail with Shimano SLX hubs
Tires
Maxxis Assegai, 2.5, 3C, EXO, TR
Brakes
Brakes
Shimano Deore M7120, 4-piston, metal pads
Brake Levers
Shimano SLX M7100, ISPEC EV
Cockpit
Stem
e*thirteen Base Stem | 7075 Aluminum; 35Ø ; XS, S, M: 40mmL, XL: 50mm
Handlebar
e*thirteen Base Handlebar | 7075 Aluminum, 20mm rise, Sweep: 9° back, 5° up; XS, S: 760mm; M, L, XL: 800mm
Grips
Rossignol lock on, diamond design with waffle grip
Headset
FSA ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, steel
Seatpost
KSRage I
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.366 mm | 1.378 mm | 1.321 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 344 mm | 344 mm |
| Front Center | 746 mm | 756 mm | 782 mm | 813 mm |
| Rake | 49 mm | 47 mm | 45 mm | 45 mm |
| Trail | 115 mm | 117 mm | 129 mm | 129 mm |
| Stack | 585 mm | 590 mm | 620 mm | 630 mm |
| Reach | 422 mm | 432 mm | 450 mm | 477 mm |
| Top Tube Length | 570 mm | 580 mm | 606 mm | 635 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 390 mm | 430 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 445 mm | 445 mm |
| Wheelbase | 1180 mm | 1190 mm | 1225 mm | 1257 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 30 mm | 30 mm |
| Wheels | 27" | 27" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
