Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 140mm -
Fork Suntour RAIDON
-
Groupset microSHIFT Advent X, Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail 140mm travel | 6061 Alloy
Suspension Fork
SR Suntour RAIDON34-Boost, 140mm travel, 15x110
Rear Shock
SR Suntour Edge Tr, 185x50 Trunnion, 8x30mm Lower Mount
Drivetrain
Rear Derailleur
Microshift ADVENT X Rear Derailleur 10 Speed
Shift Levers
Microshift ADVENT X Trail Trigger Shifter 1×10
Cassette
Shimano Deore M4100, 10-46T
Crank
Shimano Deore M5100, 30T
Bottom Bracket
Shimano BB52
Chain
Shimano HG54
Chain Guide
e*thirteen Vario
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano M410-B| J-Bend, Center Lock, 32h, TA 15x110
Rear Hub
ShimanoM400-B | J-Bend, Center Lock, 32h, TA 12x148, 11-speed
Rims
WTB ST i30 TCS 2.0 with Shimano hubs
Tires
Maxxis Minion DHF, 2.5, EXO/TR
Brakes
Brakes
Shimano MT410, 2-piston
Brake Levers
Shimano MT401
Cockpit
Stem
Rossignol MTB | 6061 Aluminum
Handlebar
Rossignol MTB | 6061 Aluminum, 30mm rise, Sweep: 9° back, 5° up
Grips
Rossignol lock on, diamond design with waffle grip
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, steel
Seatpost
KS EDGE I
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.341 mm | 1.378 mm | 1.321 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 345 mm | 345 mm |
| Front Center | 731 mm | 741 mm | 758 mm | 789 mm |
| Rake | 54 mm | 43 mm | 44 mm | 43 mm |
| Trail | 99 mm | 111 mm | 119 mm | 120 mm |
| Stack | 585 mm | 590 mm | 620 mm | 630 mm |
| Reach | 430 mm | 440 mm | 450 mm | 477 mm |
| Top Tube Length | 570 mm | 580 mm | 598 mm | 627 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 380 mm | 390 mm | 430 mm | 460 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 425 mm | 425 mm | 430 mm | 430 mm |
| Wheelbase | 1165 mm | 1165 mm | 1190 mm | 1221 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 29 mm | 29 mm |
| Wheels | 27" | 27" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
