Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Titanium -
Wheels 29" -
Travel Front 100mm -
Fork Fox Factory Float 32
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium
Suspension Fork
Options: FOX FLOAT 32 Step-Cast (SC), Factory or Performance Elite; ENVE MTN Rigid
Rear Shock
None
Drivetrain
Rear Derailleur
Options: Shimano Deore XT M8100, Shimano XTR M9100 (both 12-speed)
Front Derailleur
None
Shift Levers
Options: Shimano Deore XT M8100, Shimano XTR M9100 (both 12-speed)
Cassette
Options: Shimano Deore XT M8100, Shimano XTR M9100 (both 12-speed, 10-51 or 10-45 tooth)
Crank
Options: Shimano Deore XT, Shimano XTR, Lengths: 165mm, 170mm, 175mm
Bottom Bracket
English/BSA threaded, Options: Shimano Deore XT, Shimano XTR
Chain
Options: Shimano Deore XT M8100, Shimano XTR M9100 (both 12-speed)
Chain Guide
None
Pedals
None
Wheels
Front Hub
Options: Chris King, Industry Nine Hydra, Industry Nine 101, White Industries, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
Options: Chris King, Industry Nine Hydra, Industry Nine 101, White Industries, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
Options: ENVE M525, Industry Nine TR270, Stan's NoTubes Flow MK3, Astral Cycling Serpentine
Tires
Front: Maxxis Forekaster, Rear: Maxxis Rekon
Brakes
Brakes
Options: Shimano Deore XT, Shimano XTR; 160mm or 180mm rotors
Brake Levers
Options: Shimano Deore XT, Shimano XTR
Cockpit
Stem
ENVE M6, carbon or alloy, 31.8mm bar clamp, Carbon lengths: 40mm, 55mm, 70mm, Alloy lengths: 50mm, 65mm
Handlebar
ENVE M5, 760mm width, 5mm rise, 31.8mm clamp diameter
Grips
Options: Lizard Skins MacAskill, Lizard Skins Charger EVO
Headset
Options: Chris King i7, Cane Creek Hellbender 70 Series, Cane Creek 40 Series
Seat
Saddle
Sage Beccus, 143mm or 155mm width
Seatpost
FOX Transfer Factory dropper, 1x remote lever, Drop options: 100mm, 125mm, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.38 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm |
| Front Center | 685 mm | 710 mm | 750 mm |
| Rake | 51 mm | 51 mm | 55 mm |
| Trail | 86 mm | 86 mm | 81 mm |
| Stack | 614 mm | 627 mm | 652 mm |
| Reach | 424 mm | 444 mm | 472 mm |
| Top Tube Length | 604 mm | 628 mm | 663 mm |
| Seat Tube Angle | 73.75 ° | 73.75 ° | 73.75 ° |
| Seat Tube Length | 420 mm | 445 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 101 mm | 115 mm | 140 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1106 mm | 1131 mm | 1172 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 59 mm |
| Standover Height | 796 mm | 814 mm | 866 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Optimator completes the Sage Optimator model. There are 4 bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
Sage Optimator 2021 bike is equipped with the Fox Factory Float 32 fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on Optimator are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Sage Optimator includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
