Santa Cruz BULLIT X01 AXS RSV / Carbon CC 2024
2024 E-bike
Estimate price |
11,812$
Weight | 22.27 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Fork Fox Factory Float 38
-
Groupset X01 Eagle AXS, GX Eagle AXS -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano 630Wh Integrated -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 176cm
LG
174cm - 185cm
XL
183cm - 194cm
XXL
192cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BULLIT X01 AXS RSV / Carbon CC
Suspension Fork
RockShox Zeb Ultimate, 170mm -or- Fox 38 Float Factory
Rear Shock
RockShox Super Deluxe Ultimate, 230x62.5
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS, 12spd
Shift Levers
SRAM GX Eagle AXS Controller 2 Button
Cassette
SRAM XG1275 Eagle, 12spd, 10-50t
Crank
Shimano EM900 HollowTech Crank Arms 165mm
Chain
SRAM GX Eagle, 12spd
Chain Guide
E13 E-Spec+ AL
Wheels
Front Hub
DT Swiss 350, 15x110, Torque Cap, 6-Bolt, 28h
Rear Hub
DT Swiss 350, 12x148, XD, 6-Bolt, 24t, 32h
Rims
Front: Reserve 30|HD 29", Rear: Reserve 31|DH 27.5"
Tires
Front: Maxxis Assegai 29"x2.5", 3C, MaxxGrip, Double Down, Rear: Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, Double Down
Brakes
Brakes
SRAM Code Silver Stealth
Cockpit
Stem
Burgtec Enduro MK3, 42mm
Handlebar
Santa Cruz e35 Carbon Bar, 800mm
Grips
Santa Cruz Bicycles House Grips
Headset
Cane Creek 40 IS Integrated Headset
Seat
Saddle
WTB Silverado Medium, Ti
Seatpost
OneUp V2 Dropper Post, 31.6 -or- RockShox Reverb Stealth -or- Fox Transfer
Motor & Battery
Motor
Shimano Drive Unit DU-EP800
Battery
Shimano 630Wh Integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.326 mm | 1.309 mm | 1.302 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 789.4 mm | 818.8 mm | 847.5 mm | 878.5 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 133 mm | 133 mm | 133 mm | 133 mm |
| Stack | 621 mm | 630 mm | 648 mm | 670.4 mm |
| Reach | 450 mm | 475 mm | 495 mm | 515 mm |
| Top Tube Length | 591.3 mm | 619.2 mm | 644.9 mm | 672.1 mm |
| Seat Tube Angle | 77.2 ° | 77.1 ° | 77 ° | 76.8 ° |
| Seat Tube Length | 405 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm | 155 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1238 mm | 1267 mm | 1296 mm | 1327 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 748 mm | 747 mm | 745 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 174 cm | 183 cm | 192 cm |
| Rider Max Height | 176 cm | 185 cm | 194 cm | 201 cm |
