Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 203mm -
Travel Rear 203mm -
Fork RockShox BoXXer Select
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 172cm
MD
170cm - 180cm
LG
178cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6013 ALLOY TUBESET. Headtube: ZS44-ZS56 tapered headtube. Bearings: 37mm main pivot bearings / 28mm linkage bearings. Linkage: UD carbon linkage. Suspension: Signature TRL suspension design. Axle: 12 x 150mm rear axle. Rear Travel: 203mm.
Suspension Fork
ROCKSHOX BOXXER SELECT RC. Travel: 203mm. Technology: DebonAir / low speed compression / rebound adjust. Axle: 20x110 Maxle Stealth DH.
Rear Shock
MARZOCCHI BOMBER CR. Adjustment: Rebound Adjust. Spring Weight: 300 - 350 - 400 - 450lbs/in by size small - extra large. Length / Stroke: 241 x 76.
Drivetrain
Rear Derailleur
SRAM GX. Model: DH. Speed: 7 speed.
Shift Levers
SRAM GX. Model: DH. Speed: 1x7 speed.
Cassette
SRAM PG720 DH. Speed: 7 speed. Ratio: 11-25T.
Crank
SAMOX SARACEN CUSTOM. Chain Ring: 36T. Crank Length: 165mm.
Bottom Bracket
SAMOX SEALED CARTRIDGE.
Chain
KMC X11.
Wheels
Front Hub
FORMULA/KT. Front: DHL-93 sealed bearing 32H. Rear: KT M5HR sealed bearing 32H. Brake Fitting: 6-bolt. Front Axle Type: 20mm thru axle. Rear Axle Type: 12 x 150mm Saracen Taper-Lock. Hole: 32H.
Rear Hub
FORMULA/KT. Front: DHL-93 sealed bearing 32H. Rear: KT M5HR sealed bearing 32H. Brake Fitting: 6-bolt. Front Axle Type: 20mm thru axle. Rear Axle Type: 12 x 150mm Saracen Taper-Lock. Hole: 32H.
Rims
JALCO PHL32 OS. Hole: 32H. Size: 27.5''. Tubeless Ready: Yes.
Spokes
DOUBLE-BUTTED STAINLESS STEEL.
Tires
MAXXIS DHRII. Model: DH Casing. Size: 27.5 x 2.4.
Brakes
Brakes
SHIMANO BR-MT520. Brake Type: Hydraulic four piston. Rotor Size: 203/203mm.
Brake Levers
SHIMANO BL-MT501.
Cockpit
Stem
RACEFACE CHESTER 35. Length: 50mm. Clamp: 35mm. Type: Direct mount.
Handlebar
RACEFACE CHESTER. Width: 780mm. Rise: 20mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
PRESTINE PT-F13.
Seat
Saddle
SARACEN CUSTOM DH CRMO MTB.
Seatpost
RACEFACE CHESTER. Size: 30.9mm. Length: 325mm.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.368 mm | 1.309 mm | 1.273 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 786 mm | 806 mm | 826 mm | 854 mm |
| Rake | 53 mm | 53 mm | 53 mm | 57 mm |
| Trail | 122 mm | 122 mm | 122 mm | 117 mm |
| Stack | 602 mm | 602 mm | 602 mm | 611 mm |
| Reach | 420 mm | 440 mm | 460 mm | 480 mm |
| Top Tube Length | 593 mm | 613 mm | 630 mm | 653 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 400 mm | 400 mm | 400 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 125 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1226 mm | 1246 mm | 1266 mm | 1294 mm |
| Bottom Bracket Drop | 1 mm | 1 mm | 1 mm | 1 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 170 cm | 178 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 186 cm | 196 cm |
