Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alfine -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery Mahle-ebikemotion - intube battery, energy: 250 Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted aero tubing, forged bottom bracket shell, forged dropouts with slider belt tensioning system and Schindelhauer - belt port, integrated seat post clamp, smooth welded
Suspension Fork
Hydroforming aluminium fork (tapered), 15 mm through-axle, for post mount disc brakes
Drivetrain
Shift Levers
--
Crank
Shimano - Alfine Hollowtech II
Bottom Bracket
Shimano - Press-Fit
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Schindelhauer - high flange front hub disc, ebikemotion motor HUB Drive M1, Alexrims - CXD26 rims with eyelets, Sapim - Race spokes, 3-cross and 2-cross laced
Tires
Continental - GP Urban Classic 35-622
Brakes
Brakes
Formula - CURA disc brakes (hydraulic), 160 mm
Cockpit
Stem
Satori - Stealth, aluminium
Handlebar
LightSKIN - handlebar integrated LED-front-light
Grips
Schindelhauer - ergo leather grips
Headset
Tange Seiki integrated, tapered 1 1/8-1,5
Seat
Saddle
Brooks - Swift
Seatpost
LightSKIN - seat post integrated LED-rear-light
Motor & Battery
Motor
Mahle-ebikemotion - Motor HUB Drive M1, power: 250 W, torque: ca. 40 Nm, max. support up to 25 km/h
Battery
Mahle-ebikemotion - intube battery, energy: 250 Wh
Charger
Original charger for the MAHLE X35 models.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.389 mm | 1.376 mm | 1.36 mm | 1.391 mm |
| Stack | 557 mm | 571 mm | 586 mm | 605 mm |
| Reach | 401 mm | 415 mm | 431 mm | 435 mm |
| Top Tube Length | 560 mm | 580 mm | 600 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 150 mm | 165 mm | 180 mm | 200 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1018 mm | 1037 mm | 1058 mm | 1068 mm |
| Standover Height | 803 mm | 825 mm | 846 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
