schindelhauer Hannah 2023
2023 E-bike
Estimate price |
5,229$
Weight | 23.7 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alfine -
Suspension Rigid -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch - Powertube 500, intube battery, energy: 500 Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 175cm
MD
173cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted tubing , forged motor bracket, multi-cell down tube, forged dropouts with slider-belt-tensioning-system and Schindelhauer belt port, integrated seat post clamp, internal cable routing, smooth welded
Suspension Fork
Hydroforming aluminium fork (tapered), 15 mm through-axle, for post mount disc brakes
Drivetrain
Shift Levers
Shimano - Alfine 8-speed internal gear hub
Crank
Miranda - Delta
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Schindelhauer - high flange front hub disc, Shimano - Alfine 8-speed internal gear hub, Alexrims - EXR25 rims with eyelets, Sapim - Strong spokes, 3-cross and 2-cross laced
Tires
WTB - Horizon 47-584, with reflex stripes
Brakes
Brakes
Shimano Alfine S7000 disc brakes (hydraulic), 160 mm
Cockpit
Stem
Satori - Stealth, aluminium
Handlebar
Satori - Noirette, aluminium
Grips
Schindelhauer - ergo leather grips
Headset
Tange Seiki - integrated, 1 1/8-1.5
Seat
Saddle
Brooks - B17 S lady
Seatpost
Schindelhauer
Motor & Battery
Motor
Bosch - Active Line Plus, power: 250 W, torque: 50 Nm, max. support up to 25 km/h
Battery
Bosch - Powertube 500, intube battery, energy: 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.502 mm | 1.365 mm |
| Stack | 610 mm | 610 mm |
| Reach | 406 mm | 447 mm |
| Top Tube Length | 590 mm | 630 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Head Tube Angle | 72.5 ° | 72.5 ° |
| Head Tube Length | 200 mm | 200 mm |
| Chainstay Length | 450 mm | 450 mm |
| Wheelbase | 1067 mm | 1107 mm |
| Standover Height | 665 mm | 651 mm |
| Wheels | 650 | 650 |
| Rider Min Height | 158 cm | 173 cm |
| Rider Max Height | 175 cm | 186 cm |
About this model
Hannah is a Schindelhauer E Hannah model. Schindelhauer released 3 e-bikes variations of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter e-bikes average price
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 4773$. If we compare this with the average Commuter e-bike cost we notice that the price is 85.79% higher.
Commuter e-bikes average weight
If we make a quick analysis of the average weight of a Commuter e-bike, we get 24.02 kg (52.95 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Hannah weighs 23.7 kg (52.25 lbs) and is slightly lighter than the average. In short, the average Commuter e-bike weight is 1.35% higher than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Hannah 2023 e-bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hannah comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Schindelhauer Hannah e-bike has 2 sizes, in the range of 158 cm – 186 cm (5.18 ft – 6.1 ft). In short, it won’t be difficult to find the right one for you.
