Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Suspension Rigid
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.227 mm | 1.24 mm | 1.261 mm | 1.266 mm |
| Stack | 498 mm | 516 mm | 537 mm | 557 mm |
| Reach | 406 mm | 416 mm | 426 mm | 440 mm |
| Top Tube Length | 530 mm | 550 mm | 570 mm | 590 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 73.5 ° | 73 ° | 74 ° | 74 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 378 mm | 378 mm | 378 mm | 378 mm |
| Wheelbase | 961 mm | 982 mm | 988 mm | 1008 mm |
| Standover Height | 793 mm | 816 mm | 841 mm | 865 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
