schindelhauer Oskar 2023
2023 E-bike
Estimate price |
4,415$
Weight | 19.7 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch - Powertube 500, intube battery, energy: 500 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
168cm - 178cm
MD
176cm - 187cm
LG
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted tubing , forged motor bracket, multi-cell down tube, forged dropouts with slider-belt-tensioning-system and Schindelhauer belt port, integrated seat post clamp, internal cable routing, smooth welded, 5-year warranty
Suspension Fork
Hydroforming aluminium fork (tapered), 15 mm through-axle, for post mount disc brakes
Drivetrain
Shift Levers
-
Crank
Miranda - Delta
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Schindelhauer - high flange front hub disc, Schindelhauer - rear hub disc, Alexrims - EXR25 rims with eyelets, Sapim - Strong spokes, 3-cross laced
Tires
WTB - Horizon 47-584, with reflex stripes
Brakes
Brakes
Shimano Alfine S7000 disc brakes (hydraulic), 160 mm
Cockpit
Stem
Satori - Stealth, aluminium
Handlebar
Satori - Noirette aluminium
Grips
Schindelhauer (bolt-on)
Headset
Tange Seiki integrated, tapered 1 1/8-1,5
Seat
Saddle
FABRIC - Scoop Shallow Sport
Seatpost
LightSKIN - seat post integrated LED-rear-light
Motor & Battery
Motor
Bosch - Active Line Plus, power: 250 W, torque: 50 Nm, max. support up to 25 km/h Bosch - Performance Line (Cruise), power: 250 W, torque: 65 Nm, max. support up to 25 km/h
Battery
Bosch - Powertube 500, intube battery, energy: 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.507 mm | 1.372 mm | 1.389 mm |
| Stack | 609 mm | 609 mm | 628 mm |
| Reach | 404 mm | 444 mm | 452 mm |
| Top Tube Length | 590 mm | 630 mm | 644 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 200 mm | 200 mm | 220 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1067 mm | 1107 mm | 1122 mm |
| Standover Height | 784 mm | 807 mm | 840 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 168 cm | 176 cm | 185 cm |
| Rider Max Height | 178 cm | 187 cm | 200 cm |
About this model
Oskar completes the Schindelhauer E Oskar model. 2 e-bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter e-bikes
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Schindelhauer Oskar price was 4029$. If we compare this with the average Commuter e-bike cost we notice that the price is 56.83% higher.
Average weight for Commuter e-bikes
On a deeper look, we notice that the average weight of a Commuter e-bike is 24.02 kg (52.95 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Oskar weighs 19.7 kg (43.43 lbs) and is much lighter than the average. To sum up, it’s 21.93% lighter than the average weight of Commuter e-bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Oskar components
Fork material
Oskar has an aluminum fork, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The Oskar 2023 e-bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 168 cm – 200 cm (5.51 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
