Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alfine -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Tektro Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted aero tubing, forged horizontal drop outs with crocodile belt tensioning system and Schindelhauer - belt port, integrated seat post clamp, internal cable routing, smooth welded
Suspension Fork
Straight aluminium fork
Drivetrain
Shift Levers
--
Crank
Shimano - Alfine Hollowtech II
Bottom Bracket
BSA, Shimano - Alfine Hollowtech II
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Schindelhauer - high flange front hub, flip-flop rear hub, Alexrims - CX30 rims, Sapim - Race spokes, radial and 3-cross laced
Tires
Continental - Grand Prix 28-622
Brakes
Brakes
Tektro - R317, Tektro - FL750
Cockpit
Stem
Schindelhauer - handle bar stem combination
Handlebar
Schindelhauer - handle bar stem combination
Grips
Schindelhauer (bolt on)
Headset
Tange Seiki - integrated, 1 1/8
Seat
Saddle
FABRIC - Scoop Radius Sport
Seatpost
Schindelhauer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.301 mm | 1.353 mm | 1.387 mm | 1.404 mm | 1.366 mm |
| Stack | 502 mm | 521 mm | 541 mm | 560 mm | 579 mm |
| Reach | 386 mm | 385 mm | 390 mm | 399 mm | 424 mm |
| Top Tube Length | 520 mm | 530 mm | 540 mm | 560 mm | 590 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 389 mm | 389 mm | 389 mm | 389 mm | 389 mm |
| Wheelbase | 959 mm | 965 mm | 975 mm | 990 mm | 1020 mm |
| Standover Height | 775 mm | 799 mm | 822 mm | 843 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
