Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Brakes
Brakes
Rim
Cockpit
Stem
Reduced and integrated: this is how our stem fits into the overall look of every Schindelhauer. The segment system of our seatpost clamp has been transferred to the stem, which makes for an extremely discreet look.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.362 mm | 1.394 mm | 1.426 mm | 1.407 mm | 1.389 mm |
| Stack | 538 mm | 552 mm | 566 mm | 581 mm | 600 mm |
| Reach | 395 mm | 396 mm | 397 mm | 413 mm | 432 mm |
| Top Tube Length | 540 mm | 550 mm | 560 mm | 580 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 195 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1013 mm | 1018 mm | 1024 mm | 1044 mm | 1069 mm |
| Standover Height | 790 mm | 811 mm | 831 mm | 852 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
