Bike details
Overview
Key information split into simple groups.
Bike summary
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.362 mm | 1.394 mm | 1.426 mm | 1.407 mm | 1.389 mm |
| Stack | 538 mm | 552 mm | 566 mm | 581 mm | 600 mm |
| Reach | 395 mm | 396 mm | 397 mm | 413 mm | 432 mm |
| Top Tube Length | 540 mm | 550 mm | 560 mm | 580 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 195 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1013 mm | 1018 mm | 1024 mm | 1044 mm | 1069 mm |
| Standover Height | 790 mm | 811 mm | 831 mm | 852 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
