Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 2 × 7 -
Brakes Promax Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 3 aluminum, 700c road tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
Suspension Fork
Schwinn aluminum, 700c, aluminum steerer, 9 mm x 100 mm QR
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney, 31.8 mm clamp
Shift Levers
ST-AO70, 14-speed
Crank
Schwinn road, 48/32T
Bottom Bracket
VP, cartridge, square taper, 68 mm
Chain
KMC Z7
Pedals
Schwinn platform, nylon, toe clips and straps
Wheels
Rear Hub
Schwinn road, aluminum, 10 mm x 130 mm QR, 32H
Rims
Alex X2200, aluminum, double wall, 32H
Spokes
14G, stainless steel
Tires
Schwinn road, 700c x 28c, wire bead
Brakes
Brakes
Promax RC469, caliper, aluminum
Cockpit
Stem
Aluminum, threadless
Handlebar
Schwinn compact, aluminum, 400 mm - 440 mm width, 31.8 mm clamp
Grips
Schwinn road, gel cork tape
Headset
Threadless, ZS44, semi-cartridge bearings
Seat
Saddle
Schwinn sport, steel rails
Seatpost
Aluminum, 350 mm, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 587 mm | 597 mm | 602 mm | 615 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 531 mm | 559 mm | 574 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 531 mm | 551 mm | 589 mm |
| Head Tube Angle | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 140 mm | 170 mm | 191 mm | 216 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1001 mm | 1011 mm | 1016 mm | 1029 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 704 mm | 752 mm | 777 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
