Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 2 aluminum, 27.5" / 29" mountain tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
Suspension Fork
SR Suntour® XCT30 DS 100mm fork
Drivetrain
Rear Derailleur
Shimano Acera RD-M360
Front Derailleur
Shimano FD-TY700, 31.8 mm clamp
Shift Levers
Shimano EF500 EZ-FIRE, 24-speed
Crank
SR Suntour XCE, 42/34/24T
Bottom Bracket
VP, cartridge, square taper, 68 mm
Chain
KMC Z8.1
Pedals
Schwinn mountain, nylon
Wheels
Front Hub
Schwinn mountain disc, aluminum, 9 mm x 100 mm QR, 32H, 6-bolt
Rear Hub
Schwinn mountain disc, aluminum, 10 mm x 135 mm QR, 32H, 6-bolt
Rims
WTB® SX19 rim with alloy disc hubs, 135mm rear, 100mm front
Spokes
14G, stainless steel
Tires
WTB Transition sport, 27.5 in x 2.25 in / 29 in x 2.25 in, wire bead
Brakes
Brakes
Shimano BR-MT200, hydraulic disc, aluminum, 160 mm rotor
Cockpit
Stem
Schwinn, aluminum, threadless, 7° rise, 31.8 mm clamp
Handlebar
Schwinn, aluminum, 680 mm width, 25 mm rise, 31.8 mm clamp
Grips
Schwinn mountain Kraton
Headset
Threadless, ZS44, semi-cartridge bearings
Seat
Saddle
Schwinn mountain, steel rails
Seatpost
Aluminum, 350 mm, 15 mm offset, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.52 mm | 1.51 mm | 1.47 mm | 1.4 mm | 1.4 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 297 mm | 297 mm | 297 mm | 297 mm |
| Front Center | 622 mm | 644 mm | 668 mm | 698 mm | 718 mm | 718 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 84 mm | 84 mm | 92 mm | 84 mm | 84 mm | 84 mm |
| Stack | 564.5 mm | 583.2 mm | 616.6 mm | 626 mm | 626 mm | 626 mm |
| Reach | 370 mm | 384.5 mm | 408.6 mm | 425.8 mm | 445.8 mm | 445.8 mm |
| Top Tube Length | 539 mm | 559 mm | 584 mm | 604 mm | 624 mm | 624 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 419 mm | 445 mm | 483 mm | 483 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 424 mm | 424 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1041 mm | 1063 mm | 1106 mm | 1135 mm | 1155 mm | 1155 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 685 mm | 716 mm | 756 mm | 775 mm | 799 mm | 799 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Moab 3 completes the Schwinn Moab model. Schwinn launched 4 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2019 for 749$. In conclusion, this bike price is 154.34% smaller than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Moab 3 components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Moab 3 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
