Scott Scale Gravel 20 2025
2025 Road
Estimate price |
1,977$
Weight | 11.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset NX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Scale Alloy 6061 Custom Butted Tubing; Syncros Cable Integration System / Tapered Headtube; BB92 / UDH Interface / 12x148mm with 55mm Chainline
Suspension Fork
Scale Rigid HMF; Postmount Disc Standard; Tapered Carbon steerer
Drivetrain
Rear Derailleur
SRAM NX Eagle 12 Speed
Shift Levers
SRAM NX Eagle Trigger
Cassette
SRAM SX-PG1230 / 11-50
Crank
SRAM NX Eagle DUB; 55mm CL / 34T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN NX Eagle
Wheels
Front Hub
Formula CL-811 / 15x110mm
Rear Hub
Formula CL-3248 / 12x148mm
Rims
Syncros X-28 / 28H / Tubeless ready
Spokes
Stainless Black 15G / 1.8mm
Tires
Front: Maxxis Aspen / 29x2.4" / 120TPI Foldable Bead; Tubeless Ready / EXO, Rear: Maxxis Aspen / 29x2.4" / 120TPI Foldable Bead; Tubeless Ready / EXO
Brakes
Brakes
Shimano MT401 Disc Brake
Cockpit
Stem
Syncros DC 3.0; Syncros Cable Integration System; 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Handlebar
Syncros Alloy 6061; T shape Flat / 9° / 740mm; Syncros Performance XC lock-on grips
Headset
Syncros - Acros OE Cable Routing HS System; OD 50/62mm / ID 42/56mm
Seat
Saddle
Syncros Belcarra Regular 2.5
Seatpost
Syncros / 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.434 mm | 1.368 mm | 1.335 mm | 1.279 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 688 mm | 713 mm | 740 mm | 771 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 105 mm | 105 mm | 105 mm | 105 mm |
| Stack | 600.3 mm | 604.9 mm | 618.9 mm | 628.1 mm |
| Reach | 418.5 mm | 442.3 mm | 463.6 mm | 491.2 mm |
| Top Tube Length | 575 mm | 600.2 mm | 626 mm | 656.5 mm |
| Seat Tube Angle | 75.4 ° | 75.4 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 67.9 ° | 67.9 ° | 67.9 ° | 67.9 ° |
| Head Tube Length | 90 mm | 95 mm | 110 mm | 120 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1105 mm | 1131 mm | 1158 mm | 1189 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 752 mm | 781 mm | 800 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
