Scott Scale RC 400 2025
2025 Youth
Estimate price |
1,279$
Weight | 10.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork RST F1RST
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KIDS24 disc, Alloy 6061, custom tubing, semi int. CBR, BB68, SCOTT dropout, PM
Suspension Fork
RST F1RST 24" Air; 9x100, straight, Air Kids tune, BO-TNL, Lock-out, 60mm travel
Drivetrain
Rear Derailleur
Microshift ADVENT Active Motion RD+ with clutch; 9 Speed
Shift Levers
Microshift ADVENT Pro, quick short reach trigger, rubber pad lever, 9 Speed
Cassette
Microshift ADVENT H-Series 11-38T, 9 Speed
Crank
Prowheel, 127MM, 30T steel, w/CG PVC single cover
Bottom Bracket
Feimin, BB68, cartridge, square taper
Chain
KMC X9
Pedals
Kids Pedal FPD NW-450
Wheels
Front Hub
Formula, seal bearing, 20H, 5x100mm
Rear Hub
Formula, seal bearing, 24H, 5x135mm
Rims
Alexrims MD19, Disc
Spokes
15G, UCP, black
Tires
Front: Schwalbe Rocket Ron Evolution, ADDIX Speed, 67EPI, 24x2.35", folding, Rear: Schwalbe Rocket Ron Evolution, ADDIX Speed, 67EPI, 24x2.35", folding
Brakes
Brakes
Shimano BR-MT410
Brake Levers
Shimano BL-UR405
Cockpit
Stem
LEADTEC, 40mm, -/+7°, 31.8mm clamp
Handlebar
LEADTEC Kids riser bar alloy DB D19, 31.8mm clamp, 560mm, BS 9°; Syncros Grip Kids D19mm, Lock-on
Headset
Feimin 48/28.6/44/30, sealed bearings, semi int.
Seat
Saddle
Syncros KIDS III incl. Seatpost 27; 2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.599 mm |
| Bottom Bracket Height | 276.6 mm |
| Front Center | 592 mm |
| Rake | 38 mm |
| Stack | 550.4 mm |
| Reach | 344.3 mm |
| Top Tube Length | 518 mm |
| Seat Tube Angle | 72.5 ° |
| Seat Tube Length | 310 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 120 mm |
| Chainstay Length | 402 mm |
| Wheelbase | 990 mm |
| Bottom Bracket Drop | 42 mm |
| Standover Height | 358 mm |
| Wheels | 24" |
