Scott Voltage YZ 0.1 2020
2020 Mountain
Estimate price |
1,299$
Weight | 12.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork X Fusion Slant
-
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Voltage YZ DJ 6061 Alloy Hydroformed tubing Disc Dropout / horizontal for 135x10mm singleSpeed
Suspension Fork
X-Fusion Slant DJ 100mm travel / Air / Lo Comp / Rebound
Drivetrain
Cassette
Sprocket / 12 T
Crank
SCOTT Cr-Mo 3-piece cranks 170mm / 25T Alloy BMX sprocket
Bottom Bracket
Jien-Yuan BB92 / 19mm Axle
Chain
KMC Z510
Pedals
Wellgo B107.N flat
Wheels
Front Hub
Formula DC-51 / 15x100mm / thru axle
Rear Hub
Formula DC42-N w/tracknut / single Speed
Rims
Syncros MD25 Disc / 32H
Spokes
Stainless 14G / black / 2.0mm
Tires
Kenda K905 K-RAD 30TPI / wire / 26x2.3"
Brakes
Brakes
Tektro HDM275 / Hydr. Disc 160F/160R rotor
Brake Levers
Tektro HDM275
Cockpit
Stem
Syncros XM1.5 31.8mm / 40mm / 0°
Handlebar
Syncros Hixon 2.0 Rise 31.8mm / 800mm / 20mm Rise Syncros Pro DH lock-on grips
Headset
Syncros OE Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
Seat
Saddle
Syncros DJ1.5 / Pivotal
Seatpost
Syncros DJ1.5 / Pivotal / 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG Low |
|---|---|
| Stack Reach Ratio | 1.415 mm |
| Bottom Bracket Height | 324 mm |
| Front Center | 667 mm |
| Rake | 42 mm |
| Trail | 90 mm |
| Stack | 570.9 mm |
| Reach | 403.4 mm |
| Top Tube Length | 600 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 315 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 120 mm |
| Chainstay Length | 380 mm |
| Wheelbase | 1047 mm |
| Bottom Bracket Drop | 15 mm |
| Standover Height | 702 mm |
| Wheels | 26" |
| Rider Min Height | 120 cm |
About this model
Voltage YZ 0.1 completes the Scott Voltage model. 20 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Dirt Jump bikes average price
According to our math, the average price for a trustworthy Dirt Jump bike is 863$. However, this doesn’t mean that if you spend less money on a Dirt Jump bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Scott Voltage YZ 0.1 price was 1299$. Comparing this to the average Dirt Jump bike price, we see that the price is 50.52% higher.
Average weight for Dirt Jump bikes
Dirt Jump bikes have an average weight of 12.37 kg (27.27 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 12.8 kg (28.22 lbs), the Voltage YZ 0.1 model is slightly heavier than average. In conclusion, the average Dirt Jump bike weighs 3.48% less than Voltage YZ 0.1.
Voltage YZ 0.1 components
Fork
The fork installed on this bike is the X Fusion Slant model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Voltage YZ 0.1 are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Voltage YZ 0.1 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
