Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RST BLAZE
-
Groupset Shimano -
Suspension Hardtail -
Drivetrain 3 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sense Aluminio Hidroformado 6061 T4-T6 Tripla Espessura | Tapered | Cabeamento Interno | Sistema Post Mount
Suspension Fork
Rst Blaze 29 100 Mm Com Trava
Drivetrain
Cassette
Shimano Cs-Hg201 | 9 Velocidades | 11 X 36d
Crank
Shimano Fc-Mt210-3 | Triplo 40 X 30 X 22d (170mm)
Bottom Bracket
Shimano Bb-Mt500 | Integrado
Chain
Kmc Z9 | 112 Elos
Wheels
Rims
Sense Disc 29" | Cubo Shimano Center Lock Hb-Tx505 | Aro Alumínio 32 Furos | Raios Sapim Inox
Tires
Force XC Acces Line | 29x2.25
Brakes
Brakes
Mechanical Disc
Cockpit
Stem
Sense 75 Mm | 31,8 Mm | -10°
Handlebar
Sense 710 Mm | 31,8 Mm
Grips
Sense Com Trava
Headset
Neco H373-B52 | Integrado
Seat
Saddle
Selle Royal 1216drn Vivo Ladies
Seatpost
Sentec 31,6 Mm | 400 Mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
