serial1 Serial 1 SWITCH/MTN (Gen 2) 2024
2024 E-bike
Estimate price |
3,499$
Weight | 24.04 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Fork Suntour Zeron -
Suspension Hardtail -
Motor Brose mid-drive -
Battery 529Wh, integrated, removable -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed aluminum, welded construction, internal routing
Suspension Fork
SR Suntour ZERON35 BOOST AIR suspension fork
Wheels
Rims
27.5 x 35mm alloy rims and Sapim stainless steel spokes
Tires
Michelin E-Wild E-GUM-X 27.5 x 2.6-inch
Brakes
Brakes
TRP hydraulic four-piston disc brakes front and rear, 203mm x 2.3mm rotors
Seat
Seatpost
TranzX dropper seat post
Motor & Battery
Motor
Brose S Mag, mid-drive mounting
Battery
529Wh, integrated, removable
Remote
Brose Remote
Charger
Integrated USB-C plug capable of charging mobile devices (up to 10W, depending upon mobile device)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
