silverback S-Electro Elite AL 2 (EU) 2023
2023 E-bike
Estimate price |
5,001$
Weight | 24.6 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 145mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle -
Suspension Full -
Motor Shimano 85Nm mid-drive -
Battery Darfon 720Wh, 36V, 20Ah Li-Ion, 3.8Kg Weight -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 173cm
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy Dual Suspension with Shimano EP8 motor and Darfon 720Wh internal battery. Trail/Enduro frame with 160mm front and 145mm single-pivot rear travel. Designed to be light, nimble and easy to maintain.
Suspension Fork
Rockshox 35 Silver 160 mm Tapered, Thru Axle
Rear Shock
RockShox Deluxe Select+ RT, Linear Air Can 0 Neg, 3 Pos Tokens, Linear Reb-Low Comp Tune, 320LB Threshold, Trunnion Standard
Drivetrain
Rear Derailleur
SRAM SX Eagle, 50T Max
Shift Levers
R: SRAM SX Eagle
Cassette
SRAM SX Eagle, 11-50T
Crank
Shimano FC-EM600
Chain
SRAM SX Eagle
Wheels
Front Hub
F: Shimano Deore MT410, Boost, 110x15mm, 6 Bolt
Rear Hub
F: Shimano Deore MT410, Boost, 110x15mm, 6 Bolt
Rims
F: SUNringlé Duroc 35, STR Tubeless ready, 32mm Internal Width
Tires
F: Minion DHF, 29x2.60WT, EXO TR, Dual
Brakes
Brakes
Shimano MT200 2-Piston Hydraulic Disc
Cockpit
Stem
SURFACE Trail alloy, Ø35mm, Rise 7°
Handlebar
SURFACE alloy Trail 35mm, Backsweep 6°, Rise 12mm
Grips
SUFACE Double Density Lock-On
Headset
TOKEN TK1556SP S-Box Headset (IS52/28.6 l IS52/40)
Seat
Saddle
SURFACE E-BIKE
Seatpost
SURFACE Dropper Post with Lever, 30.9mm
Motor & Battery
Motor
Shimano EP8 Drive Unit, Mid-Position, 25km/h, 85N.m Torque
Battery
Darfon 720Wh, 36V, 20Ah Li-Ion, 3.8Kg Weight
Charger
Darfon Smart Plus, 100-240V, 4A, EU use
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.456 mm | 1.402 mm | 1.339 mm | 1.28 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 763 mm | 785 mm | 817 mm | 839 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 132 mm | 132 mm | 132 mm | 132 mm |
| Stack | 626 mm | 631 mm | 640 mm | 640 mm |
| Reach | 430 mm | 450 mm | 478 mm | 500 mm |
| Top Tube Length | 521 mm | 548 mm | 583 mm | 612 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 125 mm | 135 mm | 135 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1229 mm | 1251 mm | 1283 mm | 1305 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 805 mm | 825 mm | 847 mm | 866 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 173 cm | 181 cm | 191 cm | 200 cm |
