silverback Scento Path V 2024
2024 Mountain
Estimate price |
802$
Weight | 12.04 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 65mm -
Fork Zoom
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
167cm - 176cm
LG
174cm - 184cm
XL
182cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium City Bike, Custom Triple Butted Hydro-formed 6061 Frame, V-Brake Mounts. Supports 700C Wheelsize. Compatible mounts for Fender and Rack installation.
Suspension Fork
Zoom 187 AMS
Drivetrain
Rear Derailleur
Shimano RD-M310-L Altus, 7-speed
Front Derailleur
Shimano FD-TY300 Tourney, Band Type 31,8mm
Shift Levers
L: Shimano Tourney ST-EF41-L Shift/Brake Lever, 3-speed
Cassette
Shimano Tourney MF-TZ500-7, 14-28T
Crank
SURFACE Alloy 42/34/24T
Bottom Bracket
BSA73
Chain
PYC 7 Speed
Pedals
One Piece Alloy Pedal
Wheels
Front Hub
F: Alloy, 100x9mm QR, 32H
Rear Hub
F: Alloy, 100x9mm QR, 32H
Rims
F: 700C Alloy Rim, 32H
Tires
F: 700Cx40C Wanda Metro Elite
Brakes
Brakes
F: Melt-Forged Alloy V-Brake
Cockpit
Stem
SURFACE Alloy, Adjustable Rise
Handlebar
Alloy Handlebar, Ø31,8mm, 760mm Width, 9° Backsweep, 45mm Rise
Grips
SURFACE Push-on
Headset
Integrated 1-1/8" to 1-1/2"; ZS44/28.6 ZS56/40
Seat
Saddle
SURFACE
Seatpost
SURFACE Aluminium, Ø27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.535 mm | 1.468 mm | 1.469 mm | 1.515 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm | 291 mm |
| Stack | 594 mm | 596 mm | 617 mm | 647 mm |
| Reach | 387 mm | 406 mm | 420 mm | 427 mm |
| Top Tube Length | 550 mm | 570 mm | 590 mm | 605 mm |
| Seat Tube Angle | 74.6 ° | 74.6 ° | 74.6 ° | 74.6 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 150 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1054 mm | 1069 mm | 1085 mm | 1096 mm |
| Standover Height | 773 mm | 791 mm | 817 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 167 cm | 174 cm | 182 cm |
| Rider Max Height | 169 cm | 176 cm | 184 cm | 191 cm |
