silverback Splash Sport 2024
2024 Urban
Estimate price |
930$
Weight | 14.54 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
134cm - 147cm
SM
145cm - 159cm
MD
157cm - 171cm
LG
169cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Silverback Ladies Design - Engineered Custom Butted 6061 Aluminium, Tapered 1-1/8"-1.5" Headtube, Semi-Integrated Headset, SB Formed Stays, Replaceable Alloy Hanger
Suspension Fork
SR Suntour XCE DS 100mm Disc brake
Drivetrain
Rear Derailleur
MICROshift 8/9spd, Active Motion RD+ w/ clutch, Direct Cable Pull Design, for WIDE RANGE
Shift Levers
MICROshift Xpress 1 x 8spd, w/ optical gear indicator
Cassette
MICROshift 8s, 12-42T, Black, Steel ED Black
Crank
Surface alloy 32T
Bottom Bracket
BSA 73mm
Chain
8 speed
Pedals
One-Piece alloy
Wheels
Front Hub
Shimano Centerlock TX505, 32h, F: 100 x 9mm QR, R: 135mm x 10 QR (8/9/10spd)
Rear Hub
Shimano Centerlock TX505, 32h, F: 100 x 9mm QR, R: 135mm x 10 QR (8/9/10spd)
Rims
Surface Symmetrical Alloy, 25mm
Tires
CST C-1820 2.35"
Brakes
Brakes
Tektro Hydraulic Disc
Cockpit
Stem
Alloy stem 31.8mm, 10deg rise, 60mm for 350/400/450mm, 70mm for 500/550mm
Handlebar
Alloy Butted, 31.8mm, Width 700mm, Back Swept 9deg, Rise 5mm
Grips
Surface
Headset
Steel Semi-Integrated, ZS44/28.6 ZS56/40
Seat
Saddle
SLD specific saddle, black steel rails
Seatpost
Alloy 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.619 mm | 1.635 mm | 1.509 mm | 1.433 mm |
| Bottom Bracket Height | 294 mm | 294 mm | 294 mm | 294 mm |
| Stack | 586 mm | 600 mm | 600 mm | 609 mm |
| Reach | 362 mm | 367 mm | 397.5 mm | 425 mm |
| Top Tube Length | 535 mm | 545 mm | 575 mm | 605 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1051 mm | 1062 mm | 1092 mm | 1123 mm |
| Standover Height | 725 mm | 729 mm | 757 mm | 793 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 134 cm | 145 cm | 157 cm | 169 cm |
| Rider Max Height | 147 cm | 159 cm | 171 cm | 182 cm |
