silverback Spyke 24D (gen4) 2024
2024 Youth
Estimate price |
581$
Weight | 13.66 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
130cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydro formed 24" 6061 Aluminium, 1-1/8" Headtube 135mm OLD QR Dropouts, disc brake mounts
Suspension Fork
Zoom Steel Suspension fork, 50mm travel, Coil
Drivetrain
Rear Derailleur
Shimano Tourney RD-TY500, 7-Speed
Shift Levers
R: Shimano Revoshift SL-RV400-7R, 7-speed Grip Shift
Cassette
Shimano CS-HG200-7 12-28T, 7-speed
Crank
Surface alloy, 140mm, 32T chainring
Bottom Bracket
BSA68
Chain
Shimano CN-HG40, 7-Speed
Pedals
9/16? Ball, PP
Wheels
Front Hub
F: Alloy, 28H, 100 x 9mm QR, 6-bolt
Rear Hub
F: Alloy, 28H, 100 x 9mm QR, 6-bolt
Rims
F: 24" Alloy Single Wall, 28H
Tires
F: 24 x 2.35" Wanda P1226
Brakes
Brakes
F: Tektro MD-M280 Mechanical Disc
Cockpit
Stem
Alloy, Ø25.4mm, E:60mm, H:41mm Rise: 15°
Handlebar
Alloy, 580mm, Ø25.4mm, Sweep: 10°, H:15mm
Grips
110mm Long, Grip Shift
Headset
1-1/8" Headset, Press in cups
Seat
Saddle
Spyke custom design, steel rail
Seatpost
27.2mm x 250mm, Alloy
Fit data
Geometry
