Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
XS
143cm - 156cm
SM
153cm - 171cm
MD
169cm - 180cm
LG
178cm - 190cm
XL
188cm - 210cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy frame, Tapered headtube, contoured tubes, replaceable derailleur hanger, kickstand bracket, full length cable routing
Suspension Fork
VAXA 860 Coil, 100mm travel, Tapered Steerer, Steel Black Stanchions
Drivetrain
Rear Derailleur
Microshift, 7 Spd
Front Derailleur
Microshift 7 Spd
Shift Levers
Microshift, 3x7
Cassette
Sunrace 7 Spd, 11-28t
Crank
Surface Triple, 42/34/24T
Bottom Bracket
BSA73
Chain
PYC
Pedals
One Piece Alloy
Wheels
Front Hub
F: Alloy, 32h, 100 x 9mm QR,
Rear Hub
F: Alloy, 32h, 100 x 9mm QR,
Rims
Surface Symmetrical Double wall alloy, 29x25mm
Tires
CST C1820 29x2.35", Wire bead
Brakes
Brakes
Tektro Hydraulic disc
Cockpit
Stem
Surface Alloy 31.8mm Oversize, 10deg rise
Handlebar
Surface Alloy 700mm, Oversize. 9deg backsweep, 30mm rise
Grips
Surface
Headset
Semi Integrated ZS44/28.6 ZS56/40
Seat
Saddle
Surface Ergo, Steel Rails
Seatpost
Alloy 30.9mm, micro adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.522 mm | 1.459 mm | 1.412 mm | 1.369 mm | 1.345 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm | 325 mm | 325 mm |
| Front Center | 669 mm | 685 mm | 709 mm | 717 mm | 752 mm |
| Rake | 48 mm | 48 mm | 48 mm | 34 mm | 35 mm |
| Trail | 100 mm | 100 mm | 100 mm | 115 mm | 114 mm |
| Stack | 598 mm | 598 mm | 607 mm | 616 mm | 639 mm |
| Reach | 393 mm | 410 mm | 430 mm | 450 mm | 475 mm |
| Top Tube Length | 565 mm | 582 mm | 604 mm | 627 mm | 658 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 350 mm | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1109 mm | 1126 mm | 1150 mm | 1158 mm | 1193 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Standover Height | 735 mm | 738 mm | 735 mm | 788 mm | 797 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 143 cm | 153 cm | 169 cm | 178 cm | 188 cm |
| Rider Max Height | 156 cm | 171 cm | 180 cm | 190 cm | 210 cm |
