silverback Superspeed CF SBC 2024
2024 Mountain
Estimate price |
5,816$
Weight | 9.61 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Fox Factory Float 32
-
Groupset XX1 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 173cm
MD
170cm - 181cm
LG
179cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SB Proprietary Advanced Dynamics Carbon 29" Hardtail, Tapered 1-1/8"-1.5" Headtube, Pressfit BB Shell, MonoBurst, 148 x 12mm Boost Thru Axle Integrated Dropouts System, Replaceable Alloy hanger, Internal Cable Management System, 1 x only Frame
Suspension Fork
Fox Factory 32 Float Stepcast, FIT4, w/Remote Lockout, Boost 110
Drivetrain
Rear Derailleur
SRAM XX1 Eagle, Black
Shift Levers
SRAM XX1 Eagle 12 Speed, Black
Cassette
SRAM GX Eagle 12 Speed 10-50t, 500% Ultra-wide Range
Crank
SRAM XX1 Carbon, 34t, Black
Bottom Bracket
BB92
Chain
12 speed
Pedals
none
Wheels
Front Hub
Stans Neo
Rear Hub
Stans Neo
Rims
Stan's Crest CB7 Carbon
Tires
Maxxis Crossmark II 29x2.25", Foldable, Dual Compound, 60Tpi. Wide XC. Tubeless Ready
Brakes
Brakes
Shimano XTR 9100 Brakeset
Cockpit
Stem
Surface Alloy Stem, 31.8mm, Rise 6°; Length: S: 60mm, M: 70mm, L: 70mm
Handlebar
Surface Carbon Handlebar, Dia: 31.8mm, Backsweep: 9°; Width: S: 720mm, M: 740mm, L: 760mm
Grips
Surface
Headset
IS42/28.6 IS52/40
Seat
Saddle
Surface Race, Ti Rails
Seatpost
Surface 27.2mm Layback Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.476 mm | 1.444 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 650 | 681 mm | 704 mm |
| Rake | 47 mm | 47 mm | 46 mm |
| Trail | 90 mm | 90 mm | 91 mm |
| Stack | 606 mm | 620 mm | 634 mm |
| Reach | 395 mm | 420 mm | 439 mm |
| Top Tube Length | 575 mm | 605 mm | 628 mm |
| Seat Tube Angle | 73.4 ° | 73.4 ° | 73.4 ° |
| Seat Tube Length | 422 mm | 472 mm | 522 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1064 mm | 1095 mm | 1118 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 763 mm | 789 mm | 804 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 170 cm | 179 cm |
| Rider Max Height | 173 cm | 181 cm | 192 cm |
