simplon Rapcon Pinion Pmax Pinion E 1.12 2024
2024 E-bike
Estimate price |
11,468$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 170mm -
Fork Fox Factory Float 38
-
Groupset Pinion -
Suspension Full -
Battery Pinion E 1.12 Motor/Getriebeeinheit+FIT Ultracore Akku 960 W -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rapcon Pinion, Moon Grey Glossy | Orange Glossy, S (39,5)
Suspension Fork
FOX 38 FLOAT FACTORY 29" 170mm
Rear Shock
FOX DHX 2 Factory, 170mm
Drivetrain
Shift Levers
drivetrain Gates CDX, 39-34 für Pinion E1.12
Crank
crankarms Pinion 160mm, CNC
Bottom Bracket
Pinion, press-fit
Wheels
Rims
DT Swiss HX1501,29/275, Eddy Current 2.4/2.6
Tires
Schwalbe EDDY CURRENT 29 x 2,4" ,SuperTrail/ 27.5 x 2,6"Supe
Brakes
Brakes
drivetrain Gates CDX, 39-34 für Pinion E1.12
Cockpit
Stem
Zero III 70mm x 12°
Handlebar
Simplon CARBON RISER 800
Grips
Griffe Ergon GE10 EVO
Headset
Acros AZA-639
Seat
Saddle
w/o saddle
Seatpost
BikeYoke Revive, 160mm, 31.6
Motor & Battery
Battery
Pinion E 1.12 Motor/Getriebeeinheit+FIT Ultracore Akku 960 W
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.425 mm | 1.341 mm | 1.307 mm | 1.269 mm |
| Bottom Bracket Height | 324 mm | 324 mm | 324 mm | 324 mm |
| Front Center | 759 mm | 792 mm | 817 mm | 840 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 117 mm | 117 mm | 117 mm | 117 mm |
| Stack | 620 mm | 625 mm | 635 mm | 642 mm |
| Reach | 435 mm | 466 mm | 486 mm | 506 mm |
| Top Tube Length | 550 mm | 582 mm | 604 mm | 625 mm |
| Seat Tube Angle | 79.5 ° | 79.5 ° | 79.5 ° | 79.5 ° |
| Seat Tube Length | 395 mm | 400 mm | 420 mm | 445 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 108 mm | 108 mm | 118 mm | 126 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1204 mm | 1237 mm | 1262 mm | 1285 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm |
| Standover Height | 737 mm | 739 mm | 740 mm | 740 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rapcon Pinion Pmax Pinion E 1.12 is part of the Simplon E Rapcon model. Simplon launched 9 e-bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2024 and its price was 10588$. Doing a quick comparison, we notice that Rapcon Pinion Pmax Pinion E 1.12 price is 121.27% higher than the average cost of an Enduro e-bike.
Overview of components
Fork
Simplon Rapcon Pinion Pmax Pinion E 1.12 2024 e-bike is equipped with the Fox Factory Float 38 fork, and has 150mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Rapcon Pinion Pmax Pinion E 1.12 has a rear shock with a travel of 170mm. The model FOX DHX 2 Factory is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Simplon Rapcon Pinion Pmax Pinion E 1.12 2024, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rapcon Pinion Pmax Pinion E 1.12 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
