simplon Razorblade,Ultimate AXS,X0 Transmission 2025
2025 Mountain
Estimate price |
6,979$
Weight | 9.45 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox SID
-
Groupset X0 Eagle Transmission -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes SRAM X0 Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Razorblade IV, Cosmic Red Glossy | Black Matt, XS (36)
Suspension Fork
Rock Shox SID SL 2 Position remote 100mm
Drivetrain
Rear Derailleur
SRAM X0 Eagle Transmission
Shift Levers
SRAM X0 Eagle Transmission
Wheels
Rims
DT Swiss XRC1501-Schwalbe Racing Ray/Ralph 57-622
Tires
Schwalbe Racing Ray & Racing Ralph 29 x 2,25"
Brakes
Brakes
SRAM X0 Eagle Transmission
Cockpit
Stem
Zero III 45mm x 0°
Handlebar
Simplon CARBON RISER 760
Grips
Simplon ESI Grip
Headset
Acros AZA-642
Seat
Saddle
w/o saddle
Seatpost
KS LEV Integra 272, 100mm Southpaw
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.506 mm | 1.412 mm | 1.391 mm | 1.352 mm | 1.316 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 656 mm | 688 mm | 700 | 724 mm | 748 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 595 mm | 600 mm | 605 mm | 615 mm | 625 mm |
| Reach | 395 mm | 425 mm | 435 mm | 455 mm | 475 mm |
| Top Tube Length | 560 mm | 591 mm | 603 mm | 626 mm | 648 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 360 mm | 400 mm | 430 mm | 460 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 86 mm | 92 mm | 97 mm | 108 mm | 119 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1074 mm | 1106 mm | 1118 mm | 1142 mm | 1166 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 706 mm | 733 mm | 753 mm | 771 mm | 822 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
