simplon Stomp Pmax Sram GX Eagle Transmission 2024
2024 E-bike
Estimate price |
7,444$
Weight | 21.1 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Fork RockShox 35 Gold RL
-
Groupset GX Eagle -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery 625 Wh | optional: +250 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Stomp Pmax, Cosmic Red Glossy | Black Glossy, S (38)
Suspension Fork
35 Gold RL 140
Rear Shock
Rock Shox Deluxe SELECT+ RT
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Crank
FSA CK-745 alloy für Bosch Gen. 4 170mm
Bottom Bracket
Bosch, press-fit
Wheels
Rims
DT Swiss HX1501-Schwalbe Nobby Nic 65-622
Tires
Schwalbe NOBBY NIC,SuperTrail,29 x 2,6"
Brakes
Brakes
SRAM GX Eagle
Cockpit
Stem
Zero III 90mm x 12°
Handlebar
Simplon CARBON RISER 760
Grips
Griffe Ergon GE10 EVO
Headset
Acros AZA-636
Seat
Saddle
w/o saddle
Seatpost
BikeYoke Revive, 160mm, 31.6
Motor & Battery
Motor
Bosch Performance CX
Battery
625 Wh | optional: +250 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.418 mm | 1.368 mm | 1.326 mm | 1.3 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 757 mm | 768 mm | 799 mm | 833 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 119 mm | 111 mm | 111 mm | 111 mm |
| Stack | 609.8 mm | 615.4 mm | 630 mm | 650 |
| Reach | 430 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 570.8 mm | 592 mm | 620.5 mm | 650 |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 65 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 111.5 mm | 111.5 mm | 127.5 mm | 149.4 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1210 mm | 1221 mm | 1252 mm | 1286 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm | 29 mm |
| Standover Height | 758 mm | 758 mm | 758 mm | 758 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
