Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox Reba
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spawn Cycles 6061 T6 Alloy
Suspension Fork
Rock Shox Reba 120mm travel, rebound
Drivetrain
Cassette
14t cog and spacers
Crank
Brood Bike Co. Styx 160mm
Bottom Bracket
External, sealed cartridge bearing
Chain
Taya, black
Pedals
Wellgo alloy
Wheels
Front Hub
100x15mm alloy, sealed, quick release
Rear Hub
135 mm alloy, sealed, bolt on
Rims
Brood Bike Co. TR27, Alloy, 32h
Tires
Kenda Small Block Eight 26? x 2.10?
Brakes
Brakes
Rear: SRAM Level T, 160mm
Brake Levers
SRAM Level T
Cockpit
Stem
Spawn Cycles alloy, 40 mm
Handlebar
Brood Bike Co. A Bar Named Sue 760 mm wide, 25 mm rise
Grips
Brood Bike Co. Tenderiderz 140mm
Headset
Semi-integrated, sealed
Seat
Saddle
Brood Bike Co. Throne Pivotal
Seatpost
Pivotal Alloy, 180 mm
