Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 - T6 ALLOY, HYDROFORMED & DOUBLE BUTTED TUBING
Suspension Fork
BROOD ELDORADO, CARBON FIBER LOWER, ADJUSTABLE REBOUND, LOCKOUT - 80MM TRAVEL
Drivetrain
Crank
BROOD NARROW WIDE, CNC ALLOY, 30T
Bottom Bracket
SEALED EXTERNAL BEARING
Chain
KMC X10 SILVER
Pedals
WELLGO PLATFORM, ALLOY
Wheels
Front Hub
ALLOY, SEALED BEARING - 100 X 15
Rear Hub
ALLOY, SEALED BEARING - 135 X 9
Rims
BROOD TR27, ALLOY, 28H
Tires
BROOD MAXTION, 20" X 2.20", TUBELESS READY
Brakes
Brakes
Rear: TEKTRO HYDRAULIC DISC, 160MM
Brake Levers
TEKTRO
Cockpit
Stem
FORGED ALLOY, 40MM
Handlebar
ALLOY, 560MM WIDE, 31.8MM
Grips
BROOD TENDERIDERZ LOCK-ON
Headset
SEALED BEARING
Seat
Saddle
BROOD THRONE PIVOTAL
Seatpost
ALLOY PIVOTAL, 220MM, 30.9MM
Fit data
Geometry
