Specialized Allez Sprint Frameset 2026
2026 Road
Estimate price |
1,918$
Weight | 2.18 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Suspension Rigid
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, fully internally routed cables, threaded BB
Suspension Fork
FACT Carbon, 12x100mm thru-axle, flat-mount disc
Drivetrain
Bottom Bracket
BSA, 68mm, threaded
Seat
Seatpost
2021 S-Works Tarmac Carbon seat post, FACT Carbon, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.344 mm | 1.358 mm | 1.388 mm | 1.402 mm | 1.442 mm | 1.472 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 578 mm | 580 mm | 592 mm | 607 mm | 614 mm |
| Rake | 47 mm | 47 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 63 mm | 58 mm | 58 mm | 55 mm | 55 mm | 52 mm |
| Stack | 508 mm | 520 mm | 537 mm | 558 mm | 584 mm | 605 mm |
| Reach | 378 mm | 383 mm | 387 mm | 398 mm | 405 mm | 411 mm |
| Top Tube Length | 509 mm | 532 mm | 541 mm | 563 mm | 578 mm | 596 mm |
| Head Tube Angle | 71.75 ° | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 73.5 ° |
| Head Tube Length | 105 mm | 115 mm | 133 mm | 153 mm | 180 mm | 200 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 974 mm | 976 mm | 979 mm | 992 mm | 1006 mm | 1013 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 735 mm | 755 mm | 765 mm | 795 mm | 815 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
