Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Manitou JUNIT Comp
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, 24" Compatible, fully butted tubing, tapered head tube, BSA threaded 73mm BB shell, 12x148 thru-axle sliding dropouts, Single speed or geared compatibile, internal cable routing, 30.9mm seat tube, dropper post compatible
Suspension Fork
Manitou J-Unit Comp 24", 100mm Travel, DJ Tune, 15x110mm thru-axle, Tapered ST
Drivetrain
Cassette
13T
Crank
Prowheel, BSA-73, 140mm, Forged Arm, 30T, Boost, 30T
Bottom Bracket
73mm,W/ Ø24MM SPINDLE
Chain
KMC Z610, single speed, 1/2x3/32"
Pedals
Specialized Body Geometry Fitness, Platform, Plastic
Wheels
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Bear Pawl, 6-bolt, 12x148TA, 32h, Single Speed
Rims
P.Series, 32 Hole, 26mm ID, Disc Brake Only
Spokes
Stainless, 14g
Tires
Front: Specialized Kicker Sport, 24x2.1", Rear: Specialized Kicker Sport, 24x2.1"
Brakes
Brakes
Front: Tektro, mechanical disc, resin pads, 160mm, Rear: SRAM Level T hydraulic disc, 2-Piston Caliper
Cockpit
Stem
35mm Specialized Alloy Trail Stem
Handlebar
Specialized P.Series MTB Dirt, 6061 alloy, 9-degree backsweep, 6-degree upsweep, 38mm rise, 750mm width, 31.8mm clamp
Grips
Specialized Trail Grips, lock-on
Seat
Saddle
Soder Dirt, steel rails
Seatpost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.436 mm |
| Bottom Bracket Height | 290 mm |
| Front Center | 600 mm |
| Rake | 40 mm |
| Trail | 81 mm |
| Stack | 517 mm |
| Reach | 360 mm |
| Top Tube Length | 530 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 360 mm |
| Wheelbase | 958 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 656 mm |
| Wheels | 24" |
| Rider Min Height | 120 cm |
