Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Marzocchi Bomber DJ
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, 26/27.5" compatible, fully butted tubing, tapered head tube, BSA threaded 73mm BB shell, 12x148 thru-axle sliding dropouts, Single speed or geared compatibile, internal cable routing, 30.9mm seat tube, dropper post compatible
Suspension Fork
2025, Bomber DJ, 26in, Marzocchi, 100mm, Grip, Sweep-Adj, Matte Blk, Neutral/Matte Blk Logo, 15x100mm, 1.5 T, 37mm Rake, N/M OE
Drivetrain
Cassette
13T
Crank
Specialized P.series, Forged, 24mm Spindle, 52mm CL, 165mm Length, 30T
Bottom Bracket
73mm,W/ Ø24MM SPINDLE
Chain
KMC Z610, single speed, 1/2x3/32"
Pedals
Specialized Body Geometry Fitness, Platform, Plastic
Wheels
Front Hub
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Rear Hub
Bear Pawl, 6-bolt, 12x148TA, 32h, Single Speed
Rims
P.Series, 32 Hole, 26mm ID, Disc Brake Only
Spokes
Stainless, 14g
Tires
Front: Specialized Kicker Sport, 26x2.1", Rear: Specialized Kicker Sport, 26x2.1"
Brakes
Brakes
Front: Tektro, mechanical disc, resin pads, 160mm, Rear: SRAM Level T hydraulic disc, 2-Piston Caliper
Cockpit
Stem
35mm Specialized Alloy Trail Stem
Handlebar
Specialized P.Series MTB Dirt, 6061 alloy, 9-degree backsweep, 6-degree upsweep, 38mm rise, 750mm width, 31.8mm clamp
Grips
Specialized Trail Grips, lock-on
Seat
Saddle
Soder Dirt, steel rails
Seatpost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | P3 |
|---|---|
| Stack Reach Ratio | 1.357 mm |
| Bottom Bracket Height | 318 mm |
| Front Center | 668 mm |
| Rake | 37 mm |
| Trail | 94 mm |
| Stack | 563 mm |
| Reach | 415 mm |
| Top Tube Length | 598 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 335 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 115 mm |
| Chainstay Length | 385 mm |
| Wheelbase | 1052 mm |
| Bottom Bracket Drop | 22 mm |
| Standover Height | 691 mm |
| Wheels | 26" |
| Rider Min Height | 120 cm |
