Specialized S-Works Crux 2025
2025 Road
Estimate price |
15,124$
Weight | 6.94 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED XPLR eTap, RED AXS -
Suspension Rigid -
Drivetrain 1 × 13 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works Crux FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Drivetrain
Rear Derailleur
NEW SRAM Red XPLR, 13sp
Shift Levers
SRAM Red AXS
Cassette
NEW SRAM Red XPLR, 13sp, 10-46t
Crank
SRAM Red AXS Power Meter
Bottom Bracket
BSA, 68mm, threaded
Chain
NEW SRAM Red XPLR, 13sp
Wheels
Tires
Pathfinder Pro 2Bliss Ready, Transparent Sidewall, 700x38c
Brakes
Brakes
NEW SRAM Red XPLR, Hydraulic Disc
Cockpit
Stem
S-Works SL, alloy, titanium bolts, 6-degree rise
Handlebar
Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Seat
Saddle
S-Works Power with Mirror
Seatpost
Roval Alpinist Carbon Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.413 mm | 1.432 mm | 1.443 mm | 1.456 mm | 1.477 mm | 1.496 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 594 mm | 600 mm | 608 mm | 618 mm | 630 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 66 mm | 64 mm | 61 mm | 59 mm | 58 mm |
| Stack | 530 mm | 547 mm | 560 mm | 578 mm | 598 mm | 621 mm |
| Reach | 375 mm | 382 mm | 388 mm | 397 mm | 405 mm | 415 mm |
| Top Tube Length | 512 mm | 539 mm | 549 mm | 568 mm | 582 mm | 599 mm |
| Head Tube Angle | 70.5 ° | 71.25 ° | 71.5 ° | 72 ° | 72.25 ° | 72.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 147 mm | 167 mm | 190 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1008 mm | 1014 mm | 1023 mm | 1033 mm | 1045 mm | 1059 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 749 mm | 772 mm | 794 mm | 816 mm | 841 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
