Specialized S-Works Epic 8 EVO AXS 2026
2026 Mountain
Estimate price |
14,541$
Weight | 11.58 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Ultimate
-
Groupset XX1 Eagle AXS, XX -
Suspension Full -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 12m Carbon with Carbon Shock Extension, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain and seatpost
Suspension Fork
Rockshox Pike ULTIMATE, DebonAir, Crown adjust Charger 3.1 RC2 W/ButterCups, 130mm travel, 44mm offset
Rear Shock
RockShox Deluxe ULTIMATE, Ride Dynamics Tuned 2-position, Solo Air, 190x45mm
Drivetrain
Rear Derailleur
SRAM XX SL Eagle AXS
Shift Levers
SRAM AXS POD Ultimate Controller
Cassette
SRAM CS-1299 10-52t
Crank
SRAM XX SL Eagle Power Meter Crankset, 170mm
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Chain
SRAM XX SL Eagle
Wheels
Rims
Front: Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces, Rear: Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces
Tires
Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Industry Nine A35, 50mm, 35mm clamp
Handlebar
Roval Control Rise Carbon Handlebar, 780mm wide, 20mm rise, 35mm clamp
Grips
Specialized Trail Grips
Seat
Saddle
Specialized S-Works Power, Carbon Rails
Seatpost
RockShox Reverb AXS, 30.9mm, S: 125, M/L:150, XL: 175mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.446 mm | 1.351 mm | 1.304 mm | 1.277 mm |
| Bottom Bracket Height | 327 mm | 329 mm | 331 mm | 331 mm |
| Front Center | 720 mm | 751 mm | 782 mm | 815 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 120 mm | 120 mm | 120 mm |
| Stack | 600 mm | 601 mm | 613 mm | 632 mm |
| Reach | 415 mm | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 569 mm | 605 mm | 633 mm | 662 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 390 mm | 410 mm | 450 mm | 500 mm |
| Head Tube Angle | 65.9 ° | 65.9 ° | 65.9 ° | 65.9 ° |
| Head Tube Length | 92 mm | 95 mm | 110 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1151 mm | 1183 mm | 1214 mm | 1247 mm |
| Bottom Bracket Drop | 43 mm | 41 mm | 39 mm | 39 mm |
| Standover Height | 761 mm | 766 mm | 775 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
