Specialized S-Works Epic 8 EVO Di2 2026
2026 Mountain
Estimate price |
14,541$
Weight | 11.18 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XTR Di2 -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Shimano XTR Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 12m Carbon with Carbon Shock Extension, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain and seatpost
Suspension Fork
FOX 34 SL Factory, GRIP X Damper, HSC, LSC, LSR adjust, 130mm travel, 44mm offset, 15x110mm
Rear Shock
FOX FLOAT Factory, EVOL LV, Ride Dynamics Tuned, 2-position compression adjust, 190x45mm
Drivetrain
Rear Derailleur
Shimano XTR Di2, 12-speed
Shift Levers
Shimano XTR Di2
Cassette
Shimano XTR, 12 Speed, 10-51T
Crank
Shimano XTR 9200, 4iiii power meter, 170mm, 32T
Bottom Bracket
Shimano, BB-MT801, Threaded
Chain
Shimano XTR
Wheels
Rims
Front: Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, 24H, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces, centerlock, Rear: Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, 24H, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces, centerlock
Tires
Front: Specialized Purgatory, GRID Casing, T9 Compound, TLR, 29x2.4, Rear: Specialized Ground Control, Grid Lite Casing, T5/T7 Compound, TLR, 29x2.35
Brakes
Brakes
Front: Shimano XTR 9220, 4-piston caliper, hydraulic disc, 180mm rotor, Rear: Shimano XTR 9220, 4-piston caliper, hydraulic disc, 180mm rotor
Cockpit
Stem
Industry Nine A35, 50mm, 35mm clamp
Handlebar
Roval Control Rise Carbon Handlebar, 780mm wide, 20mm rise, 35mm clamp
Grips
Specialized Trail Grips
Seat
Saddle
Specialized S-Works Power, Carbon Rails
Seatpost
FOX Factory Transfer Neo, 30.9mm, S: 125mm, M:150mm, L/XL: 175mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.446 mm | 1.351 mm | 1.304 mm | 1.277 mm |
| Bottom Bracket Height | 327 mm | 329 mm | 331 mm | 331 mm |
| Front Center | 720 mm | 751 mm | 782 mm | 815 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 120 mm | 120 mm | 120 mm |
| Stack | 600 mm | 601 mm | 613 mm | 632 mm |
| Reach | 415 mm | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 569 mm | 605 mm | 633 mm | 662 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 390 mm | 410 mm | 450 mm | 500 mm |
| Head Tube Angle | 65.9 ° | 65.9 ° | 65.9 ° | 65.9 ° |
| Head Tube Length | 92 mm | 95 mm | 110 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1151 mm | 1183 mm | 1214 mm | 1247 mm |
| Bottom Bracket Drop | 43 mm | 41 mm | 39 mm | 39 mm |
| Standover Height | 761 mm | 766 mm | 775 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
