Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 12r carbon, FACT IS construction, aero tube shape, compact race design, tapered 1-1/8"" to 1-3/8"" head tube, internal cable routing, carbon OSBB
Suspension Fork
S-Works FACT 12r carbon, full monocoque, OS race for 1-3/8"" bearing
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2
Front Derailleur
Shimano Dura-Ace Di2
Shift Levers
Shimano Dura-Ace Di2, Flight Deck compatible, 10-speed
Cassette
Shimano Dura-Ace, 10-speed, 11-25t
Crank
S-Works FACT carbon arms and spider
Bottom Bracket
OS integrated, CeramicSpeed ceramic bearings
Chain
Shimano Dura-Ace
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Rims
Zipp Zedtech 404 carbon tubular, titanium QR
Tires
S-Works Turbo tubular w/ BlackBelt, 290TPI, aramid bead, 700x23c
Brakes
Brakes
EE Cycleworks w/Zipp cork pads
Brake Levers
Shimano Dura-Ace Di2, Flight Deck compatible
Cockpit
Stem
Zipp SL Speed stem
Handlebar
Zipp Vuka Sprint carbon aero drop bar
Headset
1-1/8"" ceramic upper and 1-3/8"" steel lower cartridge bearings, w/ custom integrated spacer
Seat
Saddle
S-Works Toupé Carbon Saddle w/ carbon base and rails
Seatpost
S-Works Venge FACT carbon, flippable 20/0mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.37 mm | 1.41 mm | 1.43 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 576 mm | 583 mm | 590 mm | 605 mm | 612 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 57 mm | 57 mm | 56 mm | 56 mm | 53 mm |
| Stack | 505 mm | 527 mm | 543 mm | 565 mm | 592 mm | 613 mm |
| Reach | 384 mm | 384 mm | 385 mm | 394 mm | 400 mm | 406 mm |
| Top Tube Length | 517 mm | 536 mm | 547 mm | 564 mm | 581 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 467 mm | 487 mm | 507 mm | 527 mm | 547 mm | 577 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 190 mm | 210 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm | 406 mm | 409 mm |
| Wheelbase | 969 mm | 969 mm | 977 mm | 985 mm | 1002 mm | 1012 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 740 mm | 765 mm | 788 mm | 808 mm | 833 mm | 859 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
S-Works + McLaren Venge belongs to the Specialized Plus model. There is 1 bike that carries this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
If you want an acceptable Aero bike you should know that the average price is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
S-Works + McLaren Venge components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Specialized S-Works + McLaren Venge 2012, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works + McLaren Venge has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
