Specialized STATUS 2 170 DH 2024
2024 Mountain
Estimate price |
4,886$
Weight | 17.18 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 180mm -
Travel Rear 170mm -
Fork RockShox BoXXer
-
Groupset Truvativ Descendant, GX -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
S2
157cm - 172cm
S3
165cm - 180cm
S4
172cm - 188cm
S5
177cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm of travel
Suspension Fork
RockShox BoXXer 29, Charger 3 RC damper, adjustable low-speed compression, adjustable rebound, 20x110mm thru-axle, 44mm offset, 180mm of travel
Rear Shock
RockShox Super Deluxe Select Coil, external rebound adjust, hydraulic bottom out, 230x62.5mm
Drivetrain
Rear Derailleur
SRAM GX DH, 7-speed, trigger
Shift Levers
SRAM GX DH, trigger, 7-speed
Cassette
SRAM GX DH, 7-speed, 11-24t
Crank
SRAM DESCENDANT DH, DUB, alloy, Direct, 34T ring, 55mm chainline, 165mm
Bottom Bracket
SRAM DUB Threaded Wide
Chain
SRAM PC1110 w/ Powerlink™
Wheels
Front Hub
Alloy, sealed cartridge bearings, 20x110mm, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Rims
Roval Alloy DH, 28mm internal width, tubeless ready. Front: 29", 28H, Rear: 27.5", 32H
Spokes
DT Swiss Industry
Tires
Front: Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3", Rear: Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
Brakes
Brakes
Front: SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm, Rear: SRAM DB MVN BRZ SJ BDPA DIR
Cockpit
Stem
Descendant 35mm Direct Mount Stem, 50mm length
Handlebar
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S2: 780mm, S3-S5: 800mm
Grips
Deity Lockjaw
Seat
Saddle
Body Geometry Henge DH, hollow Cro-Mo rails, 130mm
Seatpost
Specialized 2-bolt head, forged alloy, 5mm offset, micro-adjust, 34.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | S2 | S3 | S4 | S5 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.404 mm | 1.349 mm | 1.299 mm | 1.254 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 789 mm | 819 mm | 848 mm | 878 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 138 mm | 138 mm | 138 mm | 138 mm |
| Stack | 625 mm | 634 mm | 643 mm | 652 mm |
| Reach | 445 mm | 470 mm | 495 mm | 520 mm |
| Top Tube Length | 595 mm | 635 mm | 676 mm | 716 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 440 mm | 465 mm | 400 mm | 420 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 437 mm | 437 mm |
| Wheelbase | 1221 mm | 1250 mm | 1285 mm | 1314 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Standover Height | 735 mm | 742 mm | 748 mm | 752 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 172 cm | 177 cm |
| Rider Max Height | 172 cm | 180 cm | 188 cm | 193 cm |
