Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork RockShox Paragon Gold RL
-
Groupset X7 -
Suspension Hardtail -
Motor Specialized mid-drive -
Battery Turbo Integrated downtube battery, self-locking key release, on-board or outside bike charge capable, LED power indicators, start-up diagnostic feature, magnetic connectors, 468 Wh capacity -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Turbo alloy, smooth welding, suspension optimized geometry, fully-integrated down tube battery, internal cable routing, 700c, X12 thru-axle dropout, full fender/rack mounts
Suspension Fork
RockShox Paragon, 50mm travel
Drivetrain
Rear Derailleur
SRAM X7 Type 2, 10-speed, long cage
Shift Levers
SRAM X7 SL, 10-speed
Cassette
SRAM PG 1030, 10-speed, 11-32
Crank
Chainway, 2 pc. w/ alloy bashguard
Bottom Bracket
FSA MegaExo, outer-style
Chain
KMC X10, 10-speed, w/ reusable MissingLink
Pedals
Alloy, LSL sealed bearings, 9/16"", w/ reflectors
Wheels
Front Hub
Specialized Hi Lo disc, alloy, RCC bearing system, QR, 36h
Rims
700c disc, alloy double-wall, pin joint, 36h
Spokes
Stainless, 2.3/2.0/2.0mm
Tires
Specialized Trigger Sport, BlackBelt protection, 700x47c
Brakes
Brakes
Formula C1, dual piston, 180mm rotor
Brake Levers
Formula C1
Cockpit
Stem
Specialized 3D forged alloy, 4-bolt, 7-degree rise
Handlebar
Specialized Stout XC, flat bar, double butted 6061 alloy, 9-degree backsweep, 4-degree upsweep, 31.8mm
Grips
Specialized Body Geometry XCT, dual compound, lock-on
Headset
Ahead, cartridge bearings, alloy top cap, 8mm cone spacer
Seat
Saddle
Body Geometry Turbo, hollow Cr-Mo rails
Seatpost
Specialized, alloy, 2-bolt, 12.5mm offset, 30.9mm
Motor & Battery
Motor
Custom Specialized G45c X12
Battery
Turbo Integrated downtube battery, self-locking key release, on-board or outside bike charge capable, LED power indicators, start-up diagnostic feature, magnetic connectors, 468 Wh capacity
Charger
Custom Specialized
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 633 mm | 652 mm | 665 mm | 685 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 77 mm | 77 mm | 77 mm | 77 mm |
| Top Tube Length | 587 mm | 605 mm | 618 mm | 638 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 155 mm | 165 mm | 175 mm | 185 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1082 mm | 1100 mm | 1114 mm | 1134 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 749 mm | 786 mm | 817 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Turbo X completes the Specialized E Turbo X model. Specialized launched 2 e-bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid e-bikes
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This e-bike has the RockShox Paragon Gold RL fork installed. The fork’s travel is 50mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Specialized Turbo X 2015, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Specialized Turbo X e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
