Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Alfine, SRAM -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
50cm
162cm - 172cm
52cm
170cm - 177cm
Open
147cm - 172cm
55cm
175cm - 182cm
57cm
180cm - 188cm
60cm
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Carbon Disc w/ carbon tapered steerer, 1 1/8" - 1 1/2"
Drivetrain
Shift Levers
Alfine 11-speed, RapidFire Plus
Crank
SRAM S300, 50/52 = 170mm, 55/57/60 = 175mm
Pedals
Black body/Black cage
Wheels
Front Hub
Dynamo, PL-8, 6V-3W, 32h, Disc front, 6-bolt
Rear Hub
Alfine 11-speed Black, disc, 32h
Rims
Black, 700c, ATD470, 32º, aero profile, presta valve
Spokes
14g, stainless, black
Tires
Small Block Eight, 700x32C, Presta
Brakes
Brakes
HD-M275 hydraulic disc
Cockpit
Stem
Alloy, 31.8 clamp, +/-6 degree, 50/52cm = 100mm, 55/57cm = 110mm, 60cm = 120mm
Handlebar
Alloy, 31.8mm, 620mm width, 9 deg sweep
Grips
Dual Density Rubber, Black
Headset
10-Series, zS56 Bottom, 10, ZS44 Short
Seat
Saddle
Black with grey accent
Seatpost
Spot black alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | Open | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.432 mm | 1.409 mm | 1.34 mm | 1.436 mm | 1.441 mm | 1.404 mm |
| Front Center | 24 mm | 24 mm | 24 mm | 24 mm | 25 mm | 26 mm |
| Rake | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm |
| Trail | 125 mm | 118 mm | 118 mm | 111 mm | 108 mm | 108 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Bottom Bracket Drop | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 170 cm | 147 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 172 cm | 177 cm | 172 cm | 182 cm | 188 cm | 195 cm |
About this model
Acme is part of the Spotbrand Acme model. 3 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1999$. If we compare this with the average Fitness bike cost we notice that the price is 204.73% higher.
Acme components
Fork material
Acme has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Acme are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Spot Brand Acme is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Acme comes in 6 sizes, that range from 162 cm – 195 cm (5.31 ft – 6.4 ft). In short, you can easily find one that suits you.
