Standert Kreissäge RS Silver Dagger Shimano Dura Ace Di2 2024
2024 Road
Estimate price |
5,583$
Weight | 8.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset RED AXS -
Suspension Rigid -
Drivetrain Electronic -
Brakes Rim
Sizing
Recommended size guide.
48cm
150cm - 163cm
50cm
158cm - 170cm
52cm
166cm - 177cm
54cm
170cm - 180cm
56cm
175cm - 185cm
58cm
182cm - 192cm
60cm
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Standert Kreissäge RS
Suspension Fork
Standert full carbon integrated tapered 1 1/8"-1 1/2" flat mount
Drivetrain
Rear Derailleur
SRAM Red AXS E1
Front Derailleur
SRAM Red AXS E1
Shift Levers
SRAM Red AXS E1
Cassette
SRAM Red AXS E1 10-33
Crank
SRAM Red AXS E1
Bottom Bracket
First T47
Chain
SRAM Red AXS E1
Wheels
Tires
Schwalbe Pro One Evo TLR | +€0.00
Brakes
Brakes
Euro (Right Rear, Left Front) | +€0.00
Cockpit
Stem
Deda Superbox
Handlebar
Deda Superzero RS Carbon
Headset
Standert Integrated
Seat
Saddle
Fizik Vento Argo R1 140mm | +€0.00
Seatpost
Zipp Service Course SL Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.395 mm | 1.391 mm | 1.402 mm | 1.436 mm | 1.457 mm | 1.451 mm |
| Stack | 521 mm | 530 mm | 537 mm | 544 mm | 560 mm | 580 mm | 595 mm |
| Reach | 370 mm | 380 mm | 386 mm | 388 mm | 390 mm | 398 mm | 410 mm |
| Top Tube Length | 495 mm | 512 mm | 525 mm | 544 mm | 555 mm | 570 mm | 586 mm |
| Seat Tube Angle | 76.5 ° | 76 ° | 75.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 480 mm | 490 mm | 500 mm | 530 mm | 550 mm | 571 mm | 586 mm |
| Head Tube Angle | 71.25 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 130 mm | 145 mm | 166 mm | 181 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 969 mm | 970 mm | 974 mm | 984 mm | 986 mm | 1000 mm | 1016 mm |
| Standover Height | 741 mm | 745 mm | 758 mm | 778 mm | 794 mm | 816 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 158 cm | 166 cm | 170 cm | 175 cm | 182 cm | 188 cm |
| Rider Max Height | 163 cm | 170 cm | 177 cm | 180 cm | 185 cm | 192 cm | 198 cm |
