Standert Kreissäge RS Team Sram Force AXS D2 2024
2024 Road
Estimate price |
6,397$
Weight | 8.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Sizing
Recommended size guide.
48cm
150cm - 163cm
50cm
158cm - 170cm
52cm
166cm - 177cm
54cm
170cm - 180cm
56cm
175cm - 185cm
58cm
182cm - 192cm
60cm
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Standert Kreissäge RS
Suspension Fork
Standert full carbon integrated tapered 1 1/8"-1 1/2" flat mount
Drivetrain
Rear Derailleur
Shimano 105 Di2 R7150
Front Derailleur
Shimano 105 Di2 R7150
Shift Levers
Shimano 105 R7100 5034
Cassette
Shimano 105 CS7100 1134
Crank
Shimano 105 R7100 5034
Bottom Bracket
Standert T47
Chain
Shimano 105 CN7100
Wheels
Tires
Schwalbe Pro One Evo TLR | +€0.00
Brakes
Brakes
Euro (Right Rear, Left Front) | +€0.00
Cockpit
Handlebar
Fizik Vento Microtex 2mm | +€0.00
Headset
Standert Integrated
Seat
Saddle
Fizik Vento Argo R1 140mm | +€0.00
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.395 mm | 1.391 mm | 1.402 mm | 1.436 mm | 1.457 mm | 1.451 mm |
| Stack | 521 mm | 530 mm | 537 mm | 544 mm | 560 mm | 580 mm | 595 mm |
| Reach | 370 mm | 380 mm | 386 mm | 388 mm | 390 mm | 398 mm | 410 mm |
| Top Tube Length | 495 mm | 512 mm | 525 mm | 544 mm | 555 mm | 570 mm | 586 mm |
| Seat Tube Angle | 76.5 ° | 76 ° | 75.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 480 mm | 490 mm | 500 mm | 530 mm | 550 mm | 571 mm | 586 mm |
| Head Tube Angle | 71.25 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 130 mm | 145 mm | 166 mm | 181 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 969 mm | 970 mm | 974 mm | 984 mm | 986 mm | 1000 mm | 1016 mm |
| Standover Height | 741 mm | 745 mm | 758 mm | 778 mm | 794 mm | 816 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 158 cm | 166 cm | 170 cm | 175 cm | 182 cm | 188 cm |
| Rider Max Height | 163 cm | 170 cm | 177 cm | 180 cm | 185 cm | 192 cm | 198 cm |
