Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork DT Swiss F 535 ONE
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16.5"
168cm - 179cm
18"
177cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
DT SWISS F535 - 160mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 1 x 12 Modell 2023
Cassette
12x Eagle 10-52
Crank
1x 32
Pedals
without
Wheels
Rims
Mavic Crossmax XL 29
Brakes
Brakes
Magura MT5 4 piston brake
Cockpit
Stem
Acros Gothic 35mm
Handlebar
Acros Gothic Rizer 780mm 35mm diameter - can be shortened, height 15mm, setback 8 degrees, upsweep 5°
Seat
Saddle
Selle Italia SLR Boost SuperFlow X-Cross Titanium
Seatpost
Bike Yoke Divine Travel 125mm (16.5"), 160mm (18")
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16.5" | 18" |
|---|---|---|
| Stack Reach Ratio | 1.374 mm | 1.326 mm |
| Bottom Bracket Height | 316 mm | 316 mm |
| Front Center | 771 mm | 797 mm |
| Rake | 54 mm | 42 mm |
| Trail | 111 mm | 125 mm |
| Stack | 622.56 mm | 640.53 mm |
| Reach | 453 mm | 483 mm |
| Top Tube Length | 610 mm | 625 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 458 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° |
| Head Tube Length | 100 mm | 120 mm |
| Chainstay Length | 428 mm | 428 mm |
| Wheelbase | 1193 mm | 1218 mm |
| Bottom Bracket Drop | 58 mm | 58 mm |
| Front Travel | 120 mm | 120 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm |
| Rider Max Height | 179 cm | 190 cm |
