Stevens Avantgarde HT 2025
2025 Urban
Estimate price |
2,558$
Weight | 14.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NCX
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TB, O.L.D.: 135 mm, Brake: postmount disc 6", BB: BSA 68 mm, Front derailleur mount: clamp, Cable routing: internal (shifting)/external (brake), Fender + rack mounts
Suspension Fork
SR Suntour NCX-E Air LO, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: postmount disc 6", Fender mounts
Drivetrain
Rear Derailleur
Shimano CUES U8000 Shadow+, RD-U8020-SGS, 11-speed, Total capacity: 48 T
Front Derailleur
Shimano CUES U8000, FD-U8010-LL3, 2-speed
Shift Levers
Shimano CUES U8000, SL-U8000-L, 2-speed, I-Spec II
Cassette
Shimano CS-LG700-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-34-39-45 T
Crank
Shimano CUES U8000, Shimano FC-U8000-2, 46-32 T, Hollowtech II
Bottom Bracket
BSA, 68mm, threaded
Chain
Shimano CN-LG500, LINKGLIDE
Pedals
ATB Alu Pro Reflex
Wheels
Front Hub
Shimano DH-UR708-3D, Hub dynamo, Axle: QR15x100 mm
Rear Hub
Shimano FH-UR600, Axle: QR10x135 mm
Rims
Oxygen RM-26 Disc SL, ETRTO: 26 x 622
Tires
Continental Contact Urban, Tire size: 47-622, Foldable, Safety Pro, PureGrip Compound, Reflective stripes
Brakes
Brakes
Shimano CUES U8000, BR-U8000, Hydraulic disc brake, Postmount standard, 2 pistons
Brake Levers
Shimano CUES U8000, 3 finger, I-Spec II
Cockpit
Stem
Oxygen Scorpo, Handlebar clamp: 31.8 mm, Angle: 17°
Handlebar
Oxygen Scorpo, Width: 640 mm, Backsweep: 9°, Rise: 15 mm, Clamp: 31.8 mm
Headset
STEVENS AH Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Selle Royal Explora Male
Seatpost
Oxygen Scorpo, Length: 320 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.596 mm | 1.618 mm | 1.649 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 617 mm | 633 mm | 638 mm | 645 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 93 mm | 92 mm | 86 mm | 82 mm |
| Stack | 605 mm | 624 mm | 647 mm | 668 mm |
| Reach | 383 mm | 391 mm | 400 mm | 405 mm |
| Top Tube Length | 574 mm | 589 mm | 605 mm | 617 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 455 mm | 486 mm | 516 mm | 547 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71.5 ° |
| Head Tube Length | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1069 mm | 1085 mm | 1090 mm | 1097 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 795 mm | 819 mm | 846 mm | 871 mm |
| Wheels | 700 | 700 | 700 | 700 |
