Stevens Devil´s Trail 2023
2023 Mountain
Estimate price |
1,719$
Weight | 12.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TB, O.L.D.: 135 mm, Brake: IS disc, BB: BSA 73 mm, Front derailleur mount: direct mount (high), Cable routing: internal (shifting)/external (brake), Rack mounts
Suspension Fork
Rock Shox Recon Gold RL, Travel: 100 mm, Air suspension, Remote Lockout, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 110 mm, Brake: postmount disc 6"
Drivetrain
Rear Derailleur
Shimano Deore Shadow+, RD-M6100-SGS, 12-speed, Total capacity: 41 T
Shift Levers
Shimano Deore, SL-M6100-R, 12-speed, RAPIDFIRE PLUS
Cassette
Sunrace CSMZ602, 12-speed, Combination: 11-13-15-17-19-21-24-28-32-36-42-51 T
Crank
Shimano FC-MT510, 32 T, BB type: BSA 73 mm / 2-Piece
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-M6100
Pedals
MTB Alu Flatpedal
Wheels
Front Hub
Strummer CLTP, Axle: QR15x110 mm
Rear Hub
Formula CL-26, Axle: QR9x135 mm
Rims
Oxygen RM-M19, ETRTO: 27.5": 19 x 584 | 29": 19 x 622
Tires
Schwalbe Rocket Ron Performance, Tire size: 27.5": 57-584 | 29": 57-622, Foldable, ADDIX Compound
Brakes
Brakes
Shimano BR-MT410, Hydraulic disc brake, 2 pistons
Brake Levers
Shimano BL-MT401, 2 finger, Aluminium lever
Cockpit
Stem
Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: 6°
Handlebar
Oxygen Driver, Width: 740 mm, Backsweep: 9°, Rise: 25 mm, Clamp: 31.8 mm
Headset
STEVENS MTB Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Oxygen Havoc
Seatpost
Oxygen Driver, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.373 mm | 1.469 mm | 1.432 mm | 1.404 mm | 1.454 mm |
| Bottom Bracket Height | 301 mm | 301 mm | 301 mm | 301 mm | 301 mm |
| Front Center | 653 mm | 663 mm | 683 mm | 705 mm | 711 mm |
| Rake | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 93 mm | 79 mm | 80 mm | 83 mm | 80 mm |
| Stack | 563 mm | 608 mm | 617 mm | 632 mm | 650 |
| Reach | 410 mm | 414 mm | 431 mm | 450 mm | 447 mm |
| Top Tube Length | 565 mm | 595 mm | 615 mm | 635 mm | 640 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 366 mm | 397 mm | 446 mm | 495 mm | 545 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 435 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1083 mm | 1104 mm | 1124 mm | 1146 mm | 1152 mm |
| Bottom Bracket Drop | 50 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 731 mm | 769 mm | 801 mm | 835 mm | 873 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Devil´s Trail is part of the Stevens Devils model. Stevens launched 2 bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1587$. In conclusion, this bike price is 20.04% lower than the price of the average Crosscountry bike.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
slightly heavier than average, Devil´s Trail has a weight of 12.9 kg (28.44 lbs). To sum up, it’s 4.03% heavier than the average weight of Crosscountry bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The Devil´s Trail comes factory-installed with the RockShox Recon Gold RL fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Devil´s Trail bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Devil´s Trail comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
