Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Fox Rhythm Float 34
-
Groupset XT, e*thirteen -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube 625, 17.4Ah, 36V, lithium ion, integrated, with ABUS lock -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 34 Rhythm E-Bike+, 51mm offset, 2-position remote
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SHADOW RD+, SGS cage
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
e*thirteen e*spec Plus, 170mm length
Chain
Shimano Deore XT M8100, 12-speed
Chain Guide
Upper slider
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
SUNringlé Duroc TR35
Tires
Schwalbe Nobby Nic, Evolution, foldable, Addix compound, 29" x 2.6"
Brakes
Brakes
Shimano MT520, 4-piston, Shimano RT64 180mm CENTER LOCK rotors
Brake Levers
Shimano MT501
Cockpit
Stem
Oxygen E-Scorpo, 31.8mm bar clamp, 6° rise, Length: 60mm (16"), 70mm (18"), 80mm (20"), 90mm (22")
Handlebar
Oxygen E-Scorpo, 740mm width, 9° backsweep, 25mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Havoc
Seatpost
Oxygen E-Scorpo, 400mm length
Motor & Battery
Motor
Bosch G4 Performance Line CX Cruise, 250W, 75Nm
Battery
Bosch PowerTube 625, 17.4Ah, 36V, lithium ion, integrated, with ABUS lock
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.46 mm | 1.45 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Stack | 649 mm | 649 mm | 659 mm | 675 mm |
| Reach | 408 mm | 428 mm | 450 mm | 464 mm |
| Top Tube Length | 586 mm | 606 mm | 631 mm | 656 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68.5 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1154 mm | 1174 mm | 1200 mm | 1215 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 752 mm | 773 mm | 798 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
E-Agnello belongs to the Stevens E E Agnello model. 3 e-bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail e-bikes
Trail e-bikes weigh an average of 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 22.5 kg (49.6 lbs), the E-Agnello model is a bit lighter than average. In short, the average Trail e-bike weight is 5.33% higher than this one.
Overview of components
Fork
This e-bike has the Fox Rhythm Float 34 fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on E-Agnello are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Stevens E-Agnello is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
