Stevens E-Agnello 2023
2023 E-bike
Estimate price |
5,390$
Weight | 24.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 750, Capacity: 750 Wh/20.1 Ah, Voltage: 36 V, Technology: Li-Ion -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 DB, O.L.D.: 148 mm, Brake: postmount disc 7", BB: Bosch, Cable routing: internal
Suspension Fork
RockShox 35 Gold RL, Travel: 120 mm, Air suspension, Tapered Steerer 1 1/8" - 1.8'', O.L.D.: 110 mm, Brake: postmount disc 7", Lockout
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow+, RD-M8100-SGS, 12-speed, Total capacity: 41 T
Shift Levers
Shimano Deore, SL-M6100-IR, 12-speed, I-SPEC EV
Cassette
Shimano Deore, CS-M6100, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T
Crank
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M6100
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Strummer CLTP, Axle: QR15x110 mm
Rear Hub
Strummer M42-3, Axle: QR12x148 mm
Rims
Sun Ringlé Düroc TR35, ETRTO: 31 x 622
Tires
Schwalbe Nobby Nic Performance, Tire size: 65-622, Foldable, ADDIX compound, LiteSkin
Brakes
Brakes
Tektro HD-M535, Hydraulic disc brake, 4 pistons
Brake Levers
Tektro HD-M535, 2 finger
Cockpit
Stem
Oxygen E-Scorpo, Handlebar clamp: 31.8 mm, Angle: 5°
Handlebar
Oxygen Scorpo, Width: 740 mm, Backsweep: 9°, Rise: 25 mm, Clamp: 31.8 mm
Headset
Acros Blocklock Taper 1 1/8"-1.8", Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46
Seat
Saddle
Oxygen Havoc
Seatpost
Oxygen E-Scorpo DPR-E, Travel: 100 mm | 125 mm | 150 mm, Remote Lockout, Length: 340 mm | 390 mm | 440 mm, Diameter: 30.9 mm, Insertion depth: 100 mm
Motor & Battery
Motor
Bosch G4 Performance Line CX, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant
Battery
Bosch PowerTube 750, Capacity: 750 Wh/20.1 Ah, Voltage: 36 V, Technology: Li-Ion
Charger
Bosch 4A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.55 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 709 mm | 713 mm | 739 mm | 754 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 96 mm | 96 mm | 93 mm |
| Stack | 646 mm | 653 mm | 662 mm | 679 mm |
| Reach | 413 mm | 420 mm | 443 mm | 457 mm |
| Top Tube Length | 586 mm | 601 mm | 626 mm | 651 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 350 mm | 372 mm | 409 mm | 432 mm |
| Head Tube Angle | 67.5 ° | 68 ° | 68 ° | 68.5 ° |
| Head Tube Length | 120 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 466 mm | 466 mm | 466 mm | 466 mm |
| Wheelbase | 1166 mm | 1170 mm | 1196 mm | 1211 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 763 mm | 780 mm | 804 mm | 823 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
E-Agnello is part of the Stevens E E Agnello model. There are 4 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4976$. Doing a quick comparison, we notice that E-Agnello price is 47.88% higher than the average cost of a Trail e-bike.
Average weight for Trail e-bikes
The average weight for Trail e-bikes is 23.7 kg (52.25 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
E-Agnello weighs 24.5 kg (54.01 lbs) and is slightly heavier than the average. In conclusion, the average Trail e-bike weighs 3.38% less than E-Agnello.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
E-Agnello components
Fork
Stevens E-Agnello 2023 e-bike is equipped with the RockShox 35 Gold RL fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the E-Agnello e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the E-Agnello. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
