Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour AION
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube 500, 13.4Ah, 36V, lithium ion, integrated, with ABUS lock -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Aion35 RL-R, air spring, 51mm offset, remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, 11-speed, SHADOW RD+, GS cage, direct mount
Front Derailleur
N/A
Shift Levers
Shimano SLX M7100, 11-speed
Cassette
Shimano SLX M7000, 11-speed, 11-46 tooth
Crank
e*thirteen e*spec Plus, 170mm length
Chain
Shimano HG601, 11-speed
Chain Guide
Upper slider
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
SUNringlé Duroc TR35
Tires
Schwalbe Nobby Nic, Evolution, foldable, Addix compound, 29" x 2.6"
Brakes
Brakes
Shimano MT400, Shimano RT54 180mm CENTER LOCK rotors
Brake Levers
Shimano MT401
Cockpit
Stem
Oxygen E-Scorpo, 31.8mm bar clamp, 6° rise, Length: 60mm (16"), 70mm (18"), 80mm (20"), 90mm (22")
Handlebar
Oxygen E-Scorpo, 740mm width, 9° backsweep, 25mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Havoc
Seatpost
Oxygen E-Scorpo, 400mm length
Motor & Battery
Motor
Bosch G4 Performance Line CX Cruise, 250W, 75Nm
Battery
Bosch PowerTube 500, 13.4Ah, 36V, lithium ion, integrated, with ABUS lock
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.46 mm | 1.45 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Stack | 649 mm | 649 mm | 659 mm | 675 mm |
| Reach | 408 mm | 428 mm | 450 mm | 464 mm |
| Top Tube Length | 586 mm | 606 mm | 631 mm | 656 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68.5 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1154 mm | 1174 mm | 1200 mm | 1215 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 752 mm | 773 mm | 798 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
E-Juke is part of the Stevens E E Juke model. 3 e-bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail e-bikes
Trail e-bikes weigh an average of 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
a bit lighter than average, E-Juke has a weight of 22.1 kg (48.72 lbs). In short, the average Trail e-bike weight is 7.24% higher than this one.
E-Juke components
Fork
The SunTour AION is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the E-Juke e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Juke comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
