Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Silver
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 625, 16.7Ah, 36V, lithium ion, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox 35 Silver TK, 51mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, 11-speed, SHADOW RD+, GS cage, direct mount
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Crank
e*thirteen e*spec Plus, ISIS, 170mm length
Chain
Shimano Deore M6100, 12-speed
Chain Guide
Upper slider
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano MT410-B, 15x110mm Boost front, 12x148mm Boost rear with MICRO SPLINE driver
Rear Hub
Shimano MT410-B, 15x110mm Boost front, 12x148mm Boost rear with MICRO SPLINE driver
Rims
SUNringlé Duroc TR35
Tires
Schwalbe Nobby Nic, Performance, Addix, LiteSkin, foldable
Brakes
Brakes
Front: Shimano MT420, 4-piston, Shimano RT64 CENTER LOCK 203mm rotor, Rear: Shimano MT410, 2-piston, Shimano RT64 CENTER LOCK 180mm rotor
Brake Levers
Shimano MT401
Cockpit
Stem
Oxygen E-Scorpo, 31.8mm bar clamp, 6° rise, Length: 60mm (16"), 70mm (18"), 80mm (20"), 90mm (22")
Handlebar
Oxygen E-Scorpo, 740mm width, 9° backsweep, 25mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Havoc
Seatpost
Oxygen E-Scorpo DPR-E dropper, 125/150/170mm drop
Motor & Battery
Motor
Bosch G4 Performance Line CX Cruise, 250W, 85Nm max torque
Battery
Bosch PowerTube 625, 16.7Ah, 36V, lithium ion, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.46 mm | 1.45 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Stack | 649 mm | 649 mm | 659 mm | 675 mm |
| Reach | 408 mm | 428 mm | 450 mm | 464 mm |
| Top Tube Length | 586 mm | 606 mm | 631 mm | 656 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68.5 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1154 mm | 1174 mm | 1200 mm | 1215 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 752 mm | 773 mm | 798 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
E-Juke is a Stevens E E Juke model. There are 3 e-bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail e-bikes average weight
On a deeper look, we notice that the average weight of a Trail e-bike is 23.7 kg (52.25 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
E-Juke weighs 23.8 kg (52.47 lbs) and is slightly heavier than the average. In conclusion, the average Trail e-bike weighs 0.42% less than E-Juke.
Overview of components
Fork
The E-Juke comes factory-installed with the RockShox 35 Silver fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the E-Juke model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Juke has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
A dropper post is included with the E-Juke. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
