Stevens E-Simeto HT 2025
2025 E-bike
Estimate price |
4,652$
Weight | 23.6 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Suspension Hardtail -
Motor Bosch 250W 55Nm mid-drive -
Battery Bosch CompactTube 400, The smart system, Capacity: 400 Wh/11.1 Ah, Voltage: 36 V, Technology: Li-Ion -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Tektro Volans Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7", BB: Bosch, Cable routing: internal
Suspension Fork
STEVENS S-Lite Aluminium, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: postmount disc 7", Fender mounts
Drivetrain
Shift Levers
Enviolo Twist Controller, Twist shifter, With Display
Cassette
Gates CDX Center Track sprocket, 22 T
Crank
Oxygen E-Scorpo, BB type: Bosch / ISIS
Bottom Bracket
Bosch, press-fit
Pedals
ATB Pro Reflex
Wheels
Front Hub
Strummer TP-1, Axle: QR15x100 mm
Rims
Oxygen Taurus 26, ETRTO: 26 x 584
Tires
Continental Contact Urban, Tire size: 55-584, Safety Pro, PureGrip, Reflective stripes
Brakes
Brakes
Tektro Volans, HD-T3520-F, Hydraulic disc brake, 4 pistons
Brake Levers
Tektro HD-T532, 3 finger
Cockpit
Stem
Scorpo, Handlebar clamp: 31.8 mm, Angle: 20°
Handlebar
Oxygen E-Scorpo, Width: 640 mm, Backsweep: 35°, Rise: 20 mm, Clamp: 31.8 mm
Headset
Acros Taper 1 1/8"-1 1/2", Upper bearing cup:ZIS56/28.6, Lower bearing cup: ZS56/40
Seat
Saddle
Selle Royal ON Male
Seatpost
LightSKIN LED Alloy, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm, Integrated taillight, 5 LEDs
Motor & Battery
Motor
Bosch G4 Performance Line SX, The smart system, Continuous rated power: 250 W, Max. torque: 55 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant
Battery
Bosch CompactTube 400, The smart system, Capacity: 400 Wh/11.1 Ah, Voltage: 36 V, Technology: Li-Ion
Charger
Bosch 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.394 mm | 1.39 mm | 1.386 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 655 mm | 667 mm | 688 mm | 708 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72 mm | 72 mm | 73 mm | 72 mm |
| Stack | 582 mm | 591 mm | 610 mm | 628 mm |
| Reach | 415 mm | 424 mm | 439 mm | 453 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 397 mm | 447 mm | 477 mm | 507 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 165 mm | 175 mm | 195 mm | 215 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1118 mm | 1130 mm | 1151 mm | 1172 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 751 mm | 784 mm | 807 mm | 832 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
